Texas Instruments Line Transceiver IC, Differential, Non-Inverting, Surface Mount, 8-Pin SOIC SN65176BDR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.75mm |
| Length | 5mm |
| Model | SN65176BDR |
| Width | 3.98mm |
| Mount Type | Surface |
| Output type | Differential |
| Series | SNx5176B |
| Input Type | Differential |
| Maximum Operating Temperature | 105°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| IC Type | Line Transceiver IC |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.25V |
| Logic Family | TTL |
| Logic Function | Bus Transceiver |
| Minimum Supply Voltage | 4.75V |
| Maximum High Level Output Current | -60mA |
| Maximum Propagation Delay Time @ CL | 35ns |
| Supply Current | 70mA |
| Maximum Low Level Output Current | 60mA |
Key Features
- Operates with a minimum supply voltage of 4.75V and maximum supply voltage of 5.25V.
- Supports a maximum propagation delay time of 35ns at CL.
- Functioning temperature range from -40°C to 105°C for reliable performance.
- Maximum high level output current of -60mA and low level output current of 60mA.
- Compact dimensions of 5mm length, 3.98mm width, and 1.75mm height suitable for surface mount.
- TTL logic family with bus transceiver capability and single channel configuration.
- Non-automotive grade device without automotive standard certification.
- Series SNx5176B with low supply current draw of 70mA.
Product Description
Texas Instruments SN65176BDR is a TTL logic family line transceiver IC featuring differential input and output with non-inverting polarity, packaged in an 8-pin SOIC surface mount device. It operates at a supply voltage between 4.75V and 5.25V, enabling robust and energy-efficient communication in industrial and commercial electronic circuits.
This single-channel bus transceiver provides a maximum propagation delay of 35 nanoseconds at specified load conditions, offering fast signal transmission and reception suitable for interface IC applications.
Engineered for extended temperature operation from -40°C to 105°C, the SN65176BDR ensures reliability in diverse environments requiring stringent operational conditions. It offers a maximum high level output current of -60mA and low level output current of 60mA.
The compact surface mount SOIC package measures 5mm in length, 3.98mm in width, and 1.75mm in height, facilitating integration into space-constrained PCB layouts. The device series SNx5176B is known for its balanced performance and efficiency with a typical supply current of 70mA.
This IC is designed without automotive standard compliance, making it suitable for general purpose industrial and electronic applications but not specifically for automotive systems.
TTL logic family line transceiver with bus transceiver functionality. Single differential channel supporting non-inverting output polarity. Surface mount SOIC package for compact PCB designs. Wide operating temperature range from -40°C to 105°C for industrial use.
Low supply current of 70mA ensuring energy efficiency. Maximum propagation delay of 35ns aiding in quick data transmission. Output current capabilities of ±60mA support driving requirements. Ideal for RS-485 line driver and receiver interface applications.
This Texas Instruments SN65176BDR Line Transceiver IC is extensively used in industrial automation, communication bus systems, and interface circuits where differential signaling and speed are critical factors. It supports robust and reliable data exchange in manufacturing, laboratory instrumentation, HVAC control systems, and general semiconductor applications.
