MaxLinear Line Transceiver IC, 3 State TTL Output, Inverting Logic, 16-Pin TSSOP Package, CMOS/TTL SP3220EBCY-L

MaxLinear SP3220EBCY-L is a line transceiver integrated circuit that supports RS-232 serial communication standards with enhanced performance and reliability. It operates as a single-ended input, inverting logic device with a 3-state TTL output, housed in a compact 16-pin TSSOP surface mount package.

This transceiver is designed to operate from 3 V to 5.5 V supply voltage, with a typical supply current of 1 mA, making it suitable for low-power industrial and commercial applications. The device ensures fast data rates with a maximum propagation delay of 150 ns at specified capacitive loads.

The compact physical size of 6.5 mm in length, 5.6 mm in width, and 2 mm in height allows integration into space-constrained circuit boards commonly found in communication and control systems.

The enhanced electrostatic discharge (ESD) protection up to ±15 kV (IEC 61000-4-2 and Human Body Model) increases device robustness in harsh industrial environments.

The MaxLinear SP3220EBCY-L is pin and specification compatible with popular industry standard RS-232 line drivers and receivers, facilitating direct drop-in replacement in existing circuits for easy upgrade or repair.

Operates from a single supply voltage between 3 V and 5.5 V. Maximum propagation delay time of 150 ns at capacitive load. Surface mount 16-pin TSSOP package ensures streamlined PCB assembly. Low current consumption of 1 mA suitable for power-sensitive applications.

Temperature operating range between 0 °C and 70 °C for commercial use. Single channel line transceiver supporting RS-232 standards. Inverting logic with 3-state TTL output for flexible digital interfacing. Compact size enhances design flexibility in communication modules.

Enhanced ESD protection for improved device longevity.

This Line Transceiver IC finds wide applications in electronic communication equipment, industrial control, laboratory instruments, and other systems requiring reliable serial data transmission. Its design allows seamless integration into automated manufacturing processes.
