MaxLinear 2-Channel Line Transceiver TTL 3-State Inverting 28-Pin SSOP SP3243ECA-L
Specifications
| Country of Origin | India |
|---|---|
| Brand | MaxLinear |
| Height | 2mm |
| Length | 10.5mm |
| Model | SP3243ECA-L |
| Width | 5.6mm |
| Mount Type | Surface |
| Output type | TTL, 3 State |
| Series | SP3243E |
| Input Type | Single Ended |
| Maximum Operating Temperature | 70°C |
| Package Type | SSOP |
| Minimum Operating Temperature | 0°C |
| Polarity | Inverting |
| IC Type | Line Transceiver IC |
| Number Of Channels | 2 |
| Pin Count | 28 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS/TTL |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 3V |
| Maximum Propagation Delay Time @ CL | 1.5ns |
| Supply Current | 1mA |
Key Features
- Equipped with 2 channels for efficient data transmission.
- Utilizes CMOS/TTL logic family compatible with single-ended input signals.
- Operates from 3V minimum to 5.5V maximum supply voltage.
- Provides output in TTL, 3-state format with inverting polarity.
- Surface-mount package type SSOP with 28 pins ensures compact design.
- Maximum propagation delay time at capacitive load is 1.5ns for fast switching.
- Supports operating temperatures from 0°C to 70°C.
- Compact dimensions of 10.5mm length, 5.6mm width, and 2mm height.
Product Description
MaxLinear SP3243ECA-L is a high-performance 2-channel line transceiver designed for TTL 3-state applications with inverting output functionality. Packaged in a 28-pin SSOP surface mount, this device is optimized for use in electronic interfaces requiring fast, reliable data communication.
This line transceiver IC belongs to the CMOS/TTL logic family and accepts single-ended inputs, providing TTL level, 3-state outputs. It supports a supply voltage range of 3V to 5.5V, making it versatile for various power environments.
With a maximum propagation delay of 1.5 nanoseconds at capacitive load, the SP3243ECA-L ensures prompt signal processing suitable for demanding electronics. It operates effectively in ambient temperatures ranging from 0°C to 70°C, making it appropriate for industrial, telecommunications, and embedded system applications.
The compact 10.5mm by 5.6mm package with a height of 2mm enables efficient PCB space utilization. Low supply current of 1mA contributes to reduced power consumption. Two-channel line transceiver with inverting TTL 3-state outputs.
Compatible with CMOS/TTL logic families and single-ended inputs. Operational supply voltage from 3V up to 5.5V. Fast propagation delay of 1.5ns suitable for high-speed data lines. Surface mount 28-pin SSOP package optimizes board layout.
Temperature operation range from 0°C to 70°C for standard applications. Compact dimensions and low power consumption. No specific automotive or industry certifications, compliant to general standards.
This MaxLinear line transceiver device is ideal for electronic component assemblies, telecommunications equipment, data communication systems, and industrial control electronics requiring reliable RS-232 or TTL line interfacing.
Explore other Line Interface ICs and semiconductor components at EnvMart for comprehensive electronic solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 3V to 5.5V.
The maximum propagation delay time at capacitive load is 1.5 nanoseconds.
It supports 2 channels for data transmission.
It provides TTL level, 3-state outputs with inverting polarity.
The compact dimensions are 10.5mm in length, 5.6mm in width, and 2mm in height.
It operates effectively in ambient temperatures ranging from 0°C to 70°C.
This line transceiver is compatible with the CMOS/TTL logic family.
The supply current is 1mA, contributing to reduced power consumption.
It accepts single-ended input signals.
It is packaged in a surface-mount 28-pin SSOP configuration.
This model is suitable for telecommunications equipment, data communication systems, and industrial control electronics requiring reliable RS-232 or TTL line interfacing.
The country of origin for this product is India.
