MaxLinear 2-Channel TTL Inverting Line Transceiver, 16-Pin SOIC, 5V Supply SP232ACN-L

MaxLinear SP232ACN-L is a 2-channel line transceiver IC operating on TTL logic levels with inverting polarity, packaged in a 16-pin SOIC surface-mount form factor. It requires a minimum supply voltage of 5V and supports operation up to 6V, with a low supply current of 11mA, making it suitable for low-power embedded systems. The device is designed for reliable RS-232 communication, offering a maximum propagation delay of 3 microseconds to facilitate high-speed data transfer.

This line transceiver functions with single-ended input and TTL output signals, ensuring compatibility within a wide range of electronic devices. Its compact dimensions (9.9mm x 3.9mm x 1.75mm) allow for efficient PCB layout designs, and it maintains operational stability from 0°C to 70°C, catering to various industrial environments.

The SP232ACN-L provides two independent channels, suitable for RS-232 driver and receiver functions within serial communication systems. The inverting logic function ensures proper signal transitioning compliant with RS-232 standards.

This IC is an ideal component for interface applications in industrial controls, communication equipment, embedded systems, and instrumentation that require reliable serial data exchange. It is pin compatible with popular industry standard devices, offering a direct drop-in replacement option to simplify redesigns.

Operates with a 5V to 6V supply voltage for flexibility in power design. Supports TTL logic with inverting polarity for RS-232 compatibility. Compact 16-pin SOIC surface mount package for space-constrained designs. Low operating current consumption of 11mA for power-sensitive applications.

Maximum operating temperature of 70°C suitable for industrial environments. Fast signal propagation delay of 3 microseconds enabling efficient communication. Two independent channels supporting full duplex serial data transmission.

Compact dimensions (9.9mm x 3.9mm x 1.75mm) for optimized PCB layouts. Pin and spec compatible with industry standard line transceivers.

This MaxLinear SP232ACN-L line transceiver is suitable for a broad range of industrial, commercial, and consumer electronics applications where reliable TTL to RS-232 serial communication interfaces are required. Browse our extensive inventory for related Line Interface ICs and semiconductor components to complement your design needs.
