DiodesZetex 74LVC1G06SE-7 Buffer & Line Driver, Open Drain, Inverting, 5-Pin TSSOP 74LVC1G06SE-7

DiodesZetex 74LVC1G06SE-7 is a single-channel buffer and line driver IC designed for inverting logic applications. It features an open drain output type and comes in a compact 5-pin TSSOP surface mount package suitable for modern electronic assembly.

Operating voltage ranges from 1.65 V to 5.5 V, providing flexibility for various power supply conditions. It supports input logic levels compatible with LVTTL and TTL, while delivering output compatible with LVCMOS logic, ensuring broad compatibility with digital systems.

The device offers a maximum low-level output current of 32 mA, allowing for effective signal driving capabilities. Its supply current is low at only 200 μA, making it energy efficient for portable or low-power electronics.

Featuring a maximum propagation delay of 2.5 ns at specified load conditions, this IC supports fast signal processing requirements critical in high-speed digital circuits. The component’s operating temperature range from -40°C to 150°C makes it suitable for industrial and commercial environments with varying temperature demands.

Compact physical dimensions of 2.2 mm length, 2.2 mm width, and 1 mm height allow for space-saving designs on printed circuit boards. The device adheres to the 74LVC1G06 series logic family specifications, leveraging low-voltage CMOS technology for reliable performance.

Operates over voltage range of 1.65 to 5.5 V. Single inverting buffer channel with open drain output. Surface mount TSSOP 5-pin package optimizes PCB space. Low supply current of 200 μA for power efficiency. High maximum output current of 32 mA for driving capability.

Fast propagation delay of 2.5 ns for high-speed switching. Wide temperature range from -40°C to 150°C for harsh conditions. Input compatible with LVTTL/TTL, output compatible with LVCMOS logic. Compact and lightweight package dimensions for design flexibility.

Manufactured in China under DiodesZetex brand standards.

This buffer and line driver IC is ideal for use in electronic components, semiconductor line interface circuits, and power and connectors categories. Common applications include buffering, driving digital signals in embedded and communication devices, industrial electronics, and custom circuit designs. Its robust performance features make it suitable for laboratory, manufacturing, industrial, and commercial electronics projects.
