Texas Instruments 2-Channel Buffer & Line Driver, Open Drain, Non-Inverting, 6-Pin SOT-23 SN74LVC2G07DBVR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.1mm |
| Length | 3.05mm |
| Model | SN74LVC2G07DBVR |
| Width | 1.75mm |
| Mount Type | Surface |
| Compatibility | Input LVTTL/TTL, Output LVCMOS |
| Output type | Open Drain |
| Series | SN74LVC2G07 |
| Input Type | Single Ended |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| IC Type | Buffer & Line Driver IC |
| Number Of Channels | 2 |
| Operating Voltage | 1.65 to 5.5 V |
| Pin Count | 6 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | LVC |
| Logic Function | Driver, Buffer |
| Minimum Supply Voltage | 1.65V |
| Maximum Propagation Delay Time @ CL | 3.7ns |
| Supply Current | 10μA |
| Maximum Low Level Output Current | 32mA |
Key Features
- Features two non-inverting buffer and line driver channels.
- Operates at a low voltage range from 1.65V to 5.5V supply.
- Maximum low-level output current of 32mA.
- Has a fast propagation delay time of 3.7ns at specified load capacitance.
- Compatible with LVTTL/TTL input and LVCMOS output logic levels.
- Low quiescent supply current of approximately 10μA.
- Temperature range from -40°C to 125°C for wide industrial applications.
- Compact SOT-23 surface mount package measuring 3.05mm length and 1.75mm width.
Product Description
Texas Instruments model SN74LVC2G07DBVR is a low-voltage CMOS 2-channel buffer and line driver IC featuring open drain, non-inverting outputs in a compact 6-pin SOT-23 surface mount package. It is designed for signal buffering and driving line interfaces in electronic circuits requiring robust and reliable performance within a 1.65 to 5.5 V operating voltage range.
This device provides efficient logic level translation compatible with LVTTL/TTL inputs and LVCMOS outputs, making it suitable for mixed logic environments. The device offers a maximum low level output current of 32 mA and a typical propagation delay of 3.7 ns, enabling fast operation in high-speed digital systems.
With a low supply current around 10 μA, SN74LVC2G07DBVR supports power-efficient designs. Its wide operating temperature range of -40°C to 125°C assures suitability for industrial and automotive applications that demand reliability in harsh environments. The compact SOT-23 package (3.05 mm by 1.75 mm by 1.1 mm height) optimizes board space for modern electronics.
This buffer and line driver IC is ideal for use in interface ICs, signal conditioning, and various industrial, communication, and embedded system applications. It enables improved signal integrity and drive capability where signal boost or buffering is essential.
Features two non-inverting buffer and line driver channels. Operates with supply voltage range of 1.65 V to 5.5 V. Maximum low-level output current of 32 mA. Fast propagation delay of 3.7 ns at specified load capacitance.
Compatible with LVTTL/TTL input and LVCMOS output logic levels. Low supply current of approximately 10 μA supports power savings. Wide operating temperature from -40°C to 125°C supports harsh environments. Compact SOT-23 surface mount package for space-efficient mounting.
Applications include interface buffering, line driving, signal conditioning in industrial and communication equipment. Explore more Texas Instruments components and related Line Interface ICs at EnvMart for comprehensive electronics solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates within a voltage range of 1.65V to 5.5V.
The maximum low-level output current is 32mA.
It has a maximum propagation delay time of 3.7ns at the specified load capacitance.
It is compatible with LVTTL/TTL input logic levels and LVCMOS output logic levels.
The supply current is approximately 10μA, supporting power-efficient designs.
The compact SOT-23 package measures 3.05mm in length, 1.75mm in width, and 1.1mm in height.
It operates within a temperature range of -40°C to 125°C, suitable for industrial applications.
This model features two channels, providing non-inverting buffer and line driver functionality.
The output type is open drain, allowing for versatile interfacing options.
It has a single-ended input type, which is common in buffer and line driver applications.
It is suitable for interface buffering, line driving, and signal conditioning in industrial and communication equipment.
