MaxLinear 2-Channel Line Transceiver CMOS/TTL Inverting 16-Pin SOIC SP232AEN-L
Specifications
| Country of Origin | India |
|---|---|
| Brand | MaxLinear |
| Height | 2.65mm |
| Length | 10.3mm |
| Model | SP232AEN-L |
| Width | 7.5mm |
| Mount Type | Surface |
| Output type | CMOS/TTL |
| Input Type | Single Ended |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Polarity | Inverting |
| IC Type | Line Transceiver IC |
| Number Of Channels | 2 |
| Pin Count | 16 |
| Maximum Supply Voltage | 6V |
| Logic Family | CMOS/TTL |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 5V |
| Maximum Propagation Delay Time @ CL | 3μs |
| Supply Current | 5mA |
Key Features
- Operates with single-ended input and CMOS/TTL output logic levels.
- Supports a supply voltage range from 5V minimum to 6V maximum.
- Features low supply current of 5mA for efficient power use.
- Designed for surface mounting to a PCB with a 16-pin SOIC form factor.
- Capable of operating over a temperature range from -40°C to 85°C.
- Maximum propagation delay time at capacitive load is 3 microseconds.
- Compact dimensions with a length of 10.3mm, width of 7.5mm, and height of 2.65mm.
- No automotive standards compliance, suitable for general industrial and electronic applications.
Product Description
MaxLinear SP232AEN-L is a 2-Channel Line Transceiver component designed for RS-232 communication interfaces. This device features CMOS/TTL compatible logic, inverting polarity, and is packaged in a compact 16-pin SOIC form factor with surface mount technology.
Operating from a single supply voltage ranging from 5V to 6V, it provides low supply current typically around 5mA, making it advantageous for power-sensitive electronic systems. The maximum propagation delay time at a capacitive load is 3 microseconds, ensuring efficient data signalling at standard communication speeds.
The component supports a wide operating temperature range from -40°C to +85°C, making it reliable in various industrial and commercial environmental conditions. Its small physical dimensions (length 10.3mm, width 7.5mm, height 2.65mm) allow for compact PCB layouts, facilitating space-efficient designs.
This line transceiver is primarily used in interface circuits requiring RS-232 standard communication with two channels, facilitating data transmission and reception. Its inverting logic and CMOS/TTL output types provide compatibility with diverse digital systems in industrial electronics, instrumentation, and embedded communication devices.
Packaged as a 16-pin SOIC device, it is suitable for surface mounting applications, easing automated assembly processes and improving production efficiency. Operates with single-ended input and CMOS/TTL output logic levels.
Supports supply voltage between 5V and 6V with low current consumption. Suitable for industrial, instrumentation, and embedded communication applications. Wide operating temperature range from -40°C to 85°C for reliability.
Compact and low-profile 16-pin SOIC package for surface mount technology. Propagation delay of 3μs supports standard RS-232 data rates. Inverting polarity enabling effective RS-232 line interfacing. Low power consumption benefits battery-operated systems.
No automotive standard certification, intended for general electronics use.
This MaxLinear SP232AEN-L line transceiver is an essential component for industrial electronics and communication systems requiring reliable RS-232 interface ICs. Explore more semiconductor and interface ICs in EnvMart's extensive catalog.
Explore more products in our Line Transceiver IC category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 5V minimum to 6V maximum.
The maximum propagation delay time at a capacitive load is 3 microseconds.
It has compact dimensions with a length of 10.3mm, width of 7.5mm, and height of 2.65mm.
The output type is CMOS/TTL, which is compatible with various digital systems.
This unit can operate over a temperature range from -40°C to 85°C.
It supports 2 channels for RS-232 communication interfaces.
It accepts single-ended input, making it suitable for various applications.
The supply current is typically around 5mA, which is efficient for power-sensitive applications.
This model is designed for surface mounting on PCBs with a 16-pin SOIC form factor.
The output signal has inverting polarity, which is important for RS-232 line interfacing.
No, this model does not have automotive standards compliance and is intended for general industrial and electronic applications.
It is classified as a Line Transceiver IC, specifically designed for RS-232 communication.
