Texas Instruments Line Transceiver Differential Non-Inverting 8-Pin SOIC SN65HVD1176D

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments Line Transceiver Differential Non-Inverting 8-Pin SOIC SN65HVD1176D

Name: Texas Instruments Line Transceiver Differential Non-Inverting 8-Pin SOIC SN65HVD1176D
Brand: Texas Instruments
SKU: 202680



Category Line Transceiver IC Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	1.75mm
Length	5mm
Model	SN65HVD1176D
Width	3.98mm
Mount Type	Surface
Output type	Differential
Series	SN65HVD1176
Input Type	Differential
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
IC Type	Line Transceiver IC
Number Of Channels	1
Pin Count	8
Maximum Supply Voltage	5.5V
Logic Family	SN65
Logic Function	Line Transceiver
Minimum Supply Voltage	4.5V
Maximum High Level Output Current	-8mA
Maximum Propagation Delay Time @ CL	50ns
Supply Current	6mA
Maximum Low Level Output Current	8mA

Key Features

Designed for high-speed RS-485 communication up to 10 Mbit/s.
Single channel transceiver with differential input and output types.
Operates over a voltage range of 4.5V to 5.5V supply.
Compact SOIC surface mount package with 8 pins.
Wide operating temperature range from -40°C to 85°C.
Low supply current of 6 mA ensures energy efficiency.
Maximum propagation delay time of 50 ns at load capacitance.
Non-inverting polarity suitable for RS-485 applications.

Product Description

Texas Instruments SN65HVD1176D is a high-speed RS-485 line transceiver designed to provide reliable differential data communication for industrial and commercial applications. This Line Transceiver IC is non-inverting and supports differential signal input and output, ensuring noise-resistant data transmission.

Supplied in a compact 8-pin SOIC surface mount package, the SN65HVD1176D operates over a supply voltage range from 4.5V to 5.5V, making it suitable for a variety of low-voltage systems. It features a single communication channel with a maximum propagation delay time of 50 ns, facilitating fast and efficient signal processing.

The device supports an operating temperature range from -40°C to 85°C, allowing deployment in harsh industrial environments. It draws a low supply current of 6 mA, contributing to energy-efficient designs.

This transceiver is ideal for use in industrial automation, manufacturing communication networks, instrumentation, and control systems where robust RS-485 communication is necessary. Its non-inverting polarity and differential signaling provide improved noise immunity in electrically noisy environments.

Designed for high-speed RS-485 communication up to 10 Mbit/s. Single channel transceiver with differential input and output. Operates at supply voltages between 4.5V and 5.5V. Surface mount 8-pin SOIC package for compact applications.

Wide temperature range from -40°C to 85°C compatible with industrial use. Low supply current of 6 mA for efficient power consumption. Maximum propagation delay of 50 ns for fast signal processing. Non-inverting polarity supports reliable data transmission.

Suitable for industrial, commercial, and communication system integration.

This product enhances communication reliability in industrial machines, embedded systems, and instrumentation networks. Explore more Texas Instruments Interface ICs and Line Transceivers at EnvMart for comprehensive electronic component solutions.
