Infineon Gate Driver Module Evaluation Board EVAL-1ED3122MX12H with MOSFET for Motors EVAL1ED3122MX12HTOBO1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Model | EVAL1ED3122MX12HTOBO1 |
| For Use With | Motors |
| Standards/Approvals | RoHS |
| Kit Classification | Evaluation Board |
| Featured Device | 1ED3122MX12H |
| Kit Name | EVAL-1ED3122MX12H |
Key Features
- The board features a half-bridge configuration with two 1ED3122MU12H gate driver ICs.
- Includes TRENCHSTOP IGBT IKQ75N120CH3 for robust switching.
- An additional gate driver IC enables isolated over-current feedback from high voltage to logic control side.
- Contains a fast operational amplifier serving as comparator for over-current detection.
- Integrated filters reduce the need for external components, enhancing efficiency.
- Tight propagation delay minimizes dead time, improving system efficiency and reducing harmonic distortion.
- The design ensures superior application safety via precise thresholds and UL 1577 certification.
- High isolation capability allows use in up to 1500 V DC solar inverter applications.
Product Description
Infineon EVAL1ED3122MX12HTOBO1 Gate Driver Module Evaluation Board is a sophisticated half-bridge configuration board featuring two advanced gate driver ICs (1ED3122MU12H), designed to efficiently drive power switches including IGBTs and SiC MOSFETs. This evaluation board is optimized for motor control applications and testing.
The board comes equipped with TRENCHSTOP IGBT IKQ75N120CH3 devices to ensure reliable high-performance switching. An additional gate driver IC facilitates isolated over-current feedback, allowing precise monitoring from the high voltage side to the logic control side, essential for safety and responsive control.
A fast operational amplifier is integrated as a comparator for efficient and precise over-current detection, enhancing system protection capabilities. The built-in integrated filters minimize the requirement for external filtering components, streamlining system design.
With tight propagation delays, the board effectively reduces dead time, increasing overall system efficiency and reducing unwanted harmonic distortion, critical for demanding industrial motor drive applications.
The precise threshold and timing controls, combined with UL 1577 certification, ensure superior application safety and robustness. This product offers high isolation capacity, making it suitable for use in high voltage environments such as 1500 V DC solar inverter applications.
Typical industrial applications include motor drives, power management for electric vehicles, renewable energy inverters, and other advanced motor control systems within industrial, automotive, and renewable energy sectors.
The board features a half-bridge configuration with two gate driver ICs for robust power switch control. Equipped with TRENCHSTOP IGBT IKQ75N120CH3 ensuring high-performance switching. Isolated over-current feedback capability enhances safety and control accuracy.
Fast operational amplifier for precise over-current detection. Integrated filters reduce external component needs improving system integration. Tight propagation delay reduces dead time and harmonic distortion. UL 1577 certification confirms high safety and isolation standards.
High isolation supports use in 1500 V DC solar inverters and similar applications. Explore more Power, Motor & Robotics Development Tools and Infineon brand products at EnvMart for advanced electronics solutions.
Explore more products in our Motor Driver Boards category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The board features a half-bridge configuration with two 1ED3122MU12H gate driver ICs designed for driving power switches, including IGBTs and SiC MOSFETs.
It includes the TRENCHSTOP IGBT IKQ75N120CH3, which ensures reliable high-performance switching.
The evaluation board provides isolated over-current feedback for precise monitoring, and it has UL 1577 certification, ensuring high safety standards.
The design supports high isolation capability, allowing use in applications up to 1500 V DC, such as solar inverters.
It is optimized for motor control applications and testing, suitable for industrial motor drives, electric vehicles, and renewable energy inverters.
The board features integrated filters that minimize the need for external filtering components, enhancing system efficiency.
It has tight propagation delays that reduce dead time and harmonic distortion, improving overall system efficiency in motor drive applications.
A fast operational amplifier is integrated as a comparator for efficient and precise over-current detection.
The evaluation board complies with RoHS standards, ensuring it meets environmental regulations.
The country of origin for this product is India.
The kit classification for this product is an Evaluation Board, specifically named EVAL-1ED3122MX12H.
The featured device in this evaluation board is the 1ED3122MX12H gate driver IC.
