MaxLinear Differential Line Transceiver IC, 8-Pin SOIC, BiCMOS Logic, 4.75V-5.25V Supply, SP485ECN-L
Specifications
| Country of Origin | India |
|---|---|
| Brand | MaxLinear |
| Height | 1.75mm |
| Length | 4.9mm |
| Model | SP485ECN-L |
| Width | 3.9mm |
| Mount Type | Surface |
| Output type | Differential |
| Series | SP485E |
| Input Type | Differential |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| IC Type | Line Transceiver IC |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.25V |
| Logic Family | BiCMOS |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 4.75V |
| Maximum Propagation Delay Time @ CL | 60ns |
| Supply Current | 900μA |
Key Features
- The transceiver supports a supply voltage range of 4.75V to 5.25V.
- It features one communication channel with differential input and output configurations.
- The device operates reliably from 0°C to 70°C ambient temperature.
- The maximum propagation delay time at the specified load capacitance is 60ns.
- Low supply current of 900μA ensures efficient power usage.
- The SP485E series offers reliable RS-485 and RS-422 protocol compatibility.
- Surface-mounted SOIC package facilitates standard industrial PCB assembly.
- No automotive standard compliance but suitable for general industrial and communication applications.
Product Description
MaxLinear SP485ECN-L is a differential line transceiver IC designed for robust industrial and commercial communication systems. Featuring BiCMOS logic technology, this device supports differential input and output signals, providing reliable data transmission over balanced lines.
Operating within a voltage supply range of 4.75V to 5.25V, and optimized for low power consumption with a supply current of only 900μA, it is ideal for power-conscious designs. The device accommodates ambient operating temperatures from 0°C to 70°C, suited for typical industrial environments.
Packaged in a compact 8-pin SOIC surface-mount form factor with dimensions 4.9mm by 3.9mm by 1.75mm, it facilitates easy PCB integration. Maximum propagation delay time is rated at 60ns under CL conditions, supporting fast communication speeds.
The SP485E series transceivers are designed for uses such as RS-485 and RS-422 serial communication interfaces commonly found in industrial automation, instrumentation, data acquisition systems, and control applications. They provide pin and specification compatibility with popular industry devices, ensuring straightforward replacement and interoperability.
The IC features differential signaling for noise immunity and data integrity over long cable lengths. Surface mount SOIC packaging enables efficient pickup and soldering in automated production lines. Low quiescent current extends device longevity and reduces system power demands.
Industrial temperature rating ensures dependable operation in typical ambient conditions. The device comes in a tube packaging format ready for machine insertion to improve manufacturing throughput. Explore more from MaxLinear semiconductor product offerings and related line interface ICs at EnvMart for seamless integration into your projects.
Explore more products in our Differential Line Driver category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SP485ECN-L operates within a supply voltage range of 4.75V to 5.25V.
The maximum propagation delay time at the specified load capacitance is 60ns.
It operates reliably in ambient temperatures ranging from 0°C to 70°C.
This model supports one communication channel with differential input and output configurations.
The device is packaged in an 8-pin SOIC surface-mount format.
The supply current for this line transceiver is 900μA, which ensures efficient power usage.
It belongs to the BiCMOS logic family, which is known for low power consumption and high performance.
Yes, it is designed for reliable compatibility with RS-485 and RS-422 communication protocols.
The dimensions of this model are 4.9mm in length, 3.9mm in width, and 1.75mm in height.
It utilizes differential signaling, which enhances noise immunity and data integrity over long cable lengths.
The country of origin for this line transceiver is India.
This model is suitable for general industrial and communication applications, particularly in automation and data acquisition systems.
