Microchip 1200 V 10 A Schottky Barrier Diode Through Hole TO-247 MSC010SDA120B
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Model | MSC010SDA120B |
| Mount Type | Through Hole |
| Series | MSC0 |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Maximum Continuous Forward Current If | 10A |
| Peak Reverse Repetitive Voltage Vrrm | 1200V |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 75A |
| Maximum Forward Voltage Vf | 1.8V |
Key Features
- The diode features low forward voltage for improved efficiency.
- Incorporates soft recovery characteristics minimizing switching losses.
- Boasts low leakage current ensuring reliability in power applications.
- Allows high surge forward current capacity of 75 A for transient conditions.
- Operates within a temperature range of -55°C to 175°C for harsh environments.
- RoHS compliant ensuring environmental safety and compatibility.
- Designed for power and parallel diode applications requiring fast switching.
- Mount type is through hole for secure PCB installation.
Product Description
Microchip MSC010SDA120B is a high-performance Schottky Barrier Diode rated for a maximum continuous forward current of 10 A and a peak reverse repetitive voltage of 1200 V. Packaged in a TO-247 through hole mount type, this diode is optimized for power applications requiring fast switching and high efficiency.
The diode incorporates soft recovery characteristics to reduce switching losses and improve overall system reliability. Featuring a low forward voltage of 1.8 V and low leakage current, it supports applications where power conservation is critical.
With a peak non-repetitive forward surge current rating of 75 A, it withstands transient surges effectively. Its wide operating temperature range from -55°C minimum to 175°C maximum ensures reliable performance in demanding industrial, power supply, and automotive electronic systems.
The MSC010SDA120B is fully RoHS compliant, supporting environmentally conscious product designs. It suits uses in power rectification, power supply protection, and parallel diode configurations in industrial, manufacturing, and electronic control equipment.
The diode features low forward voltage for improved efficiency. Incorporates soft recovery characteristics minimizing switching losses. Boasts low leakage current ensuring reliability in power applications. Allows high surge forward current capacity of 75 A for transient conditions.
Operates within a temperature range of -55°C to 175°C for harsh environments. RoHS compliant ensuring environmental safety and compatibility. Designed for power and parallel diode applications requiring fast switching. Mount type is through hole for secure PCB installation.
Explore Microchip semiconductors and discrete components for reliable performance in your electronic projects and industrial machinery. Discover similar products in our Schottky Barrier Diode category for precise power management solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of the MSC010SDA120B is 10 A.
This model has a peak reverse repetitive voltage rating of 1200 V.
The diode is packaged in a TO-247 type, which is suitable for through hole mounting.
It operates within a temperature range of -55°C to 175°C.
The maximum forward voltage drop is 1.8 V.
The peak non-repetitive forward surge current rating is 75 A.
Yes, this diode is fully RoHS compliant, ensuring environmental safety and compatibility.
It is designed for power rectification, power supply protection, and parallel diode configurations in industrial and electronic control applications.
The diode incorporates soft recovery characteristics that minimize switching losses, enhancing overall system reliability.
The MSC010SDA120B is manufactured in India.
This model uses a through hole mount type for secure PCB installation.
The diode belongs to the MSC0 series.
