DiodesZetex Precision Timer Circuit 8-Pin SOIC Surface Mount 4.5V-16V NE555S-13

DiodesZetex NE555S-13 precision timer circuit is an 8-pin SOIC surface mount semiconductor device designed to provide highly stable timing pulses for electronic circuits. It operates at a supply voltage range between 4.5V and 16V and supports a monostable mode of operation, allowing precise control of time delay with an external resistor and capacitor.

This Timer Circuit maintains accurate frequency and duty cycle control using two external resistors and one capacitor, making it suitable for precise timing, pulse generation, and oscillator applications in industrial, laboratory, and consumer electronics.

The device is rated for operation from 0°C up to 70°C, providing reliable performance within typical ambient temperature ranges.

Featuring a compact 8-pin SOIC surface mount package with dimensions approximately 4.95mm length and 1.5mm height, this timer is ideal for modern PCB assembly, enhancing production efficiency while minimizing board footprint.

The propagation delay is measured under a 15pF capacitive load, ensuring predictable timing characteristics for design accuracy.

This component is widely applicable in electronic devices requiring timing control such as clocks, timers, pulse generation circuits, and waveform shaping in industrial automation, consumer electronics, and embedded system designs.

Operates with a supply voltage range of 4.5V to 16V. Single internal timer with 8-pin SOIC package. Temperature range from 0°C to 70°C for stable operation. Surface mount package type facilitates compact circuit layouts.

Accurate frequency and duty cycle control using external components. Propagation delay tested at 15pF capacitance for design precision. Compliant with RoHS standards for environmental safety. Versatile applications in industrial, laboratory, and consumer electronics.
