Crydom HD Series Panel Mount Solid State Relay 110 A Load, 530 V AC Load, 32 V Control HD48110

Crydom HD48110 is a panel mount solid state relay from the HD Series supporting up to 110 A load current and 530 V AC load voltage with control voltage of 32 V. Designed for industrial automation, it provides robust and reliable switching capabilities for heavy industrial loads.

This relay uses SCR output technology allowing zero voltage or instantaneous turn-on outputs, improving efficiency and lifetime. The HD series is known for excellent thermal performance aided by Direct Bonded Copper (DBC) substrate technology, enhancing heat dissipation for reliable operation under continuous heavy loads.

The product features a compact design with dimensions of 23 mm height, 22.6 mm width, and 45.7 mm length for convenient panel mounting. Its IP20 rating provides adequate protection from solid objects in industrial environments.

The relay can operate in extreme temperatures ranging from -40°C to 80°C and has a low off state leakage current of just 1 mA, contributing to reduced power loss in circuits. Screw terminal connections enable secure and stable wiring.

Crydom HD48110 is UL recognized for the US and Canada and CSA approved, complying with RoHS directives and VDE standards for safety and environmental compliance. These features make it suitable for demanding industries including manufacturing, HVAC control systems, power management, and automation installations.

The package does not include a heat sink. Users should refer to the manufacturers’ datasheet for proper heat sink selection and load current de-rating at temperatures above 25°C. Supports maximum load current of 110 A suitable for heavy-duty applications.

Operates at a maximum load voltage of 530 V AC ensuring robust performance. Panel mount type with screw terminals for secure installation. Wide operating temperature range from -40°C to 80°C ensures reliability in harsh environments.

Features SCR output type designed for industrial heavy loads. Compact dimensions, height 23 mm, width 22.6 mm, length 45.7 mm for easy panel integration. IP20 rated for protection against solid objects with robust construction.

Low off state leakage current of 1 mA minimizes power loss. Compliant with UR, RoHS, and CSA standards ensuring quality and safety. Direct Bonded Copper (DBC) technology for superior thermal management and durability.
