Vishay 600 V 30 A General Purpose Rectifier & Schottky Diode TO-247AD 2L VS-E5TX1506THN3
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 29.27mm |
| Length | 10.51mm |
| Model | VS-E5TX1506THN3 |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247AD 2L |
| Minimum Operating Temperature | -55°C |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 30A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 185A |
| Maximum Forward Voltage Vf | 1.3V |
Key Features
- This diode supports a maximum continuous forward current of 30 amperes.
- It features a peak reverse repetitive voltage rating of 600 volts.
- The device has a low maximum forward voltage drop of 1.3 volts, enhancing efficiency.
- Operational temperature range spans from -55 °C to a maximum of 175 °C junction temperature.
- The diode is AEC-Q101 automotive qualified, suitable for high-reliability applications.
- Its hyperfast switching characteristics minimize switching losses in power converters.
- Optimized for high-speed operation including LLC output rectification stages of EV/HEV battery chargers.
- Constructed with polyimide passivation for enhanced durability.
Product Description
Vishay VS-E5TX1506THN3 is a general purpose rectifier and Schottky diode offering a voltage rating of 600 V and a continuous forward current capacity of 30 A, housed in a TO-247AD 2L package.
Designed to provide a unique balance of low conduction and switching losses, this diode is especially suitable for soft switched and resonant converters as well as medium frequency hard switching converters. Its hyperfast switching capabilities and optimized forward voltage drop render it ideal for improving efficiency in high-speed LLC output rectification stages found in electric vehicle and hybrid electric vehicle on-board battery chargers.
The device operates reliably within a temperature range of -55 °C to 175 °C, with AEC-Q101 automotive qualification ensuring compliance with rigorous automotive standards. This diode’s robust polyimide passivation enhances its operational durability and longevity in demanding industrial environments.
The compact dimensions of 10.51 mm length and 29.27 mm height facilitate easy integration into power electronics circuits. Additional features include a peak reverse current of 500 μA and a peak non-repetitive forward surge current of 185 A, which contribute to its resilience in high power applications.
Maximum continuous forward current of 30 A ensures high current handling capacity. Peak reverse repetitive voltage of 600 V provides substantial voltage blocking capability. Low forward voltage drop of 1.3 V enhances energy efficiency.
AEC-Q101 automotive qualification supports high reliability demands. Optimized for high-speed switching and applications in EV/HEV battery chargers. Polyimide passivation enhances component protection. Compact TO-247AD 2L package for versatile mounting options.
This rectifier and Schottky diode is suitable for use in industrial power management, automotive electronics, battery charger design, and general high-speed rectification applications across electronics manufacturing and semiconductor industries.
Discover more Schottky diode and rectifier solutions in the Electronics & Electricals Semiconductor category at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this diode is 30 amperes.
This model has a peak reverse repetitive voltage rating of 600 volts.
The diode features a low maximum forward voltage drop of 1.3 volts, enhancing efficiency.
The operational temperature range spans from -55 °C to a maximum of 175 °C junction temperature.
The dimensions of the TO-247AD 2L package are 10.51 mm in length and 29.27 mm in height.
This model is AEC-Q101 automotive qualified, ensuring compliance with rigorous automotive standards.
The peak non-repetitive forward surge current rating is 185 amperes.
It uses a through hole mounting type.
The peak reverse current is rated at 500 μA.
This diode is suitable for industrial power management, automotive electronics, and battery charger design, among other high-speed rectification applications.
It is classified as a general purpose rectifier and Schottky diode.
It has hyperfast switching characteristics that minimize switching losses in power converters, making it optimized for high-speed operation.
