Semikron Danfoss Diode/Thyristor Module SCR 1600 V, 70 A, 150 mA, 9 kA, 1.6 V SKKH 72/16 E
Specifications
| Country of Origin | Slovakia |
|---|---|
| Brand | Semikron Danfoss |
| Model | SKKH 72/16 E |
| Mount Type | Panel |
| Maximum Operating Temperature | 130°C |
| Package Type | A-43 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 5 |
| Rated Average On-State Current Irms | 70A |
| Thyristor Type | SCR |
| Repetitive Peak Reverse Voltage VDRM | 1600V |
| Surge Current Rating | 9kA |
| Maximum Gate Trigger Current Igt | 150mA |
| Maximum Holding Current Ih | 500mA |
| Maximum Gate Trigger Voltage Vgt | 2V |
| Peak On-State Voltage | 1.6V |
| Repetitive Peak Off-State Current | 100mA |
Key Features
- Thyristor module features an SCR type construction for controlled switching.
- Encapsulated module with an electrically isolated base plate for secure mounting.
- Operates efficiently within -40°C to 130°C temperature range.
- Includes 5 pins with a panel mount type for easy integration.
- Maximum gate trigger current of 150 mA and gate trigger voltage up to 2 V ensure precise control.
- Peak on-state voltage of 1.6 V delivers stable conduction performance.
- Suitable for applications such as battery chargers, welders, plating equipment, and regulated power supplies.
Product Description
Semikron Danfoss SKKH 72/16 E Diode/Thyristor Module SCR offers robust electrical performance with a repetitive peak reverse voltage of 1600 V and a surge current rating of 9 kA. This module employs an SCR thyristor type, encapsulated in an A-43 package with an electrically isolated base plate, making it reliable for panel mounting applications.
It provides a rated average on-state current of 70 A and supports a gate trigger current up to 150 mA with a voltage maximum of 2 V, allowing precise activation and control. The device can operate safely within a temperature range from -40°C to 130°C, accommodating various industrial and commercial environments.
This thyristor module is ideal for use in battery chargers, welders, plating equipment, regulated power supplies, and temperature or speed control circuits. Its stable peak on-state voltage of 1.6 V and repetitive peak off-state current of 100 mA ensure consistent performance. Featuring 5 pins and panel mount design, it facilitates straightforward installation in electrical systems.
Thyristor module features an SCR type construction for controlled switching. Encapsulated module with an electrically isolated base plate for secure mounting. Operates efficiently within the -40°C to 130°C temperature range.
Panel mount type with 5 pin count for integration flexibility. Maximum gate trigger current and voltage are 150 mA and 2 V respectively. Rated average on-state current of 70 A with a surge current of 9 kA. Peak on-state voltage of 1.6 V ensures stable conduction.
Suitable for various industrial, laboratory, and manufacturing applications. Country of origin is Slovakia. This new product is a UL recognized component, ensuring compliance with safety standards. Explore more from Semikron Danfoss and browse related Thyristor Modules at EnvMart for industrial and commercial electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this module is 130°C.
The rated average on-state current is 70 A.
This thyristor module has a repetitive peak reverse voltage of 1600 V.
The surge current rating for this model is 9 kA.
This module features 5 pins.
The peak on-state voltage is 1.6 V.
The minimum operating temperature for this model is -40°C.
This module employs an SCR type construction for controlled switching.
The maximum gate trigger current is 150 mA.
This thyristor module is suitable for applications such as battery chargers, welders, plating equipment, and regulated power supplies.
The maximum gate trigger voltage is 2 V.
The country of origin for this module is Slovakia.
