i-Autoc KSJ Series Solid State Relay, 20 A Load, Panel Mount, 100 V Load, 32V Control KSJ100D20-L(068)

i-Autoc KSJ100D20-L(068) KSJ Series Solid State Relay is a high-quality panel-mounted relay designed for effective DC output electrical control. With a maximum load current of 20 A and a load voltage up to 100 V DC, it is ideal for a variety of industrial and automation applications including DC heating, power control, valve actuation, and motor operations.

This relay operates with a DC control voltage ranging from 4 V to 32 V, providing flexible control options. It features zero-cross switching functionality, which minimizes electromagnetic interference and enhances switching performance. Its IP20-rated touch-safe cover provides user protection against accidental contact with live parts.

The compact relay measures 58.6 mm in length, 45.7 mm in width, and 27 mm in height, making it suitable for panel mounting in control cabinets and electrical enclosures. The terminal type is screw, ensuring secure and reliable electrical connections. Its operating temperature range from -30°C to +80°C allows use in various industrial and environmental conditions.

With opto-isolation between input and output, the relay ensures high dielectric strength of ≥2500 VAC rms, protecting sensitive circuitry. It complies with industry standards CCC, CE, and RoHS, assuring product quality and environmental safety. The relay exhibits low off-state leakage current of 0.1 mA, contributing to energy efficiency and reduced power losses.

Typical applications include DC heating systems, solar energy controls, DC valves, and motor drivers, making it suitable for industrial automation, manufacturing processes, and renewable energy systems. Its robust design and reliable switching characteristics ensure long operational life in demanding electrical environments.

The product originates from China and meets all necessary quality and safety requirements for use in domestic and industrial electrical circuits. Installation is straightforward via panel mounting, enabling compact and organized control panel layouts.

Supports load current up to 20 amperes for robust performance. Panel mount type ensures easy and secure installation. Operates with a control voltage range from 4 to 32 volts DC. Withstands operating temperatures from -30°C to 80°C for versatile environments.

Features zero cross switching to reduce electrical noise and interference. Equipped with IP20 rated touch-safe cover for user safety. Compact dimensions of 58.6mm length, 45.7mm width, and 27mm height. Output type includes SCR and Triac, suitable for DC output applications.

Complies with standards including CCC, CE, and RoHS for quality assurance. Opto-isolation ensures electrical isolation between input and output circuits. Explore more high-quality Solid State Relays and related electronic components at EnvMart for your industrial, automation, and electrical needs.
