onsemi Zener Diode 8.2 V 1.5 W Surface Mount 2-Pin DO-214AC 1SMA5923BT3G

onsemi 1SMA5923BT3G Zener Diode is a reliable semiconductor component designed for voltage regulation and protection in electronic circuits. It is configured as a single diode in the 1SMA59xxBT3G series, optimized for surface mounting on printed circuit boards using the DO-214AC package.

With a nominal Zener voltage of 8.2 volts and a power dissipation capacity of 1.5 watts, this diode efficiently maintains a stable voltage in power supply systems and voltage reference applications. The ±5% Zener voltage tolerance ensures predictable performance in sensitive electronics.

The diode's maximum reverse leakage current of 2.5 microamperes minimizes power loss, enhancing energy efficiency. It operates reliably over a temperature range from -65°C to 150°C, allowing its use in harsh and automotive environments compliant with the AEC-Q101 standard.

The compact physical dimensions (5.59 mm length, 2.2 mm height) and surface mount design make it ideal for high-density electronic assemblies. Its 2-pin configuration simplifies PCB layout and soldering processes.

Applications include industrial, automotive, consumer electronics, and power management systems where voltage regulation and over-voltage protection are critical. The product meets RoHS compliance for environmental safety.

This diode provides a nominal Zener voltage of 8.2 V with a ±5% tolerance. It supports a maximum power dissipation of 1.5 watts for reliable operation. The device features a surface mount construction for efficient PCB integration.

Its maximum reverse leakage current is minimal at 2.5 µA, ensuring low current loss. The diode has a test current of 45.7 mA, supporting precise voltage regulation. Operating temperature ranges from -65°C to 150°C suitable for diverse environments.

The device complies with RoHS standards and meets the AEC-Q101 automotive quality requirements. Dimensions include a length of 5.59 mm and a height of 2.2 mm, suitable for compact electronics. Explore more on Zener Diodes and semiconductor components in the Electronics & Electricals category on EnvMart for industrial and commercial applications.
