Vishay 100 V 1 A Schottky Diode 2-Pin Surface Mount DO-214AC SS1H10-E3/61T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.09mm |
| Length | 4.5mm |
| Model | SS1H10-E3/61T |
| Width | 2.79mm |
| Mount Type | Surface |
| Series | SS1H10 |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 0.62V |
Key Features
- Maximum continuous forward current of 1 ampere ensures reliable operation.
- Peak reverse repetitive voltage rating of 100 volts for robust protection.
- Low forward voltage drop of 0.62 volts enhances efficiency.
- Peak non-repetitive forward surge current of 50 amperes supports high transient loads.
- Wide operating temperature range from -65°C to 175°C for extreme conditions.
- Single diode configuration with 2 pins suitable for surface mount assembly.
- High performance with very fast switching action and low power loss.
- Suitable for industrial, electronic components, power circuits, and semiconductor applications.
Product Description
Vishay SS1H10-E3/61T is a high-performance Schottky diode designed for fast switching and low forward voltage drop. This 2-pin diode is housed in a compact DO-214AC package, delivering a maximum continuous forward current of 1 ampere and a peak reverse repetitive voltage of 100 volts. Its low forward voltage drop of 0.62 volts minimizes power loss and heat generation, making it ideal for power rectification in electronic circuits.
The device supports a peak non-repetitive forward surge current of 50 amperes, ensuring durability during transient conditions. It operates reliably across a wide temperature range from -65°C to 175°C, suitable for harsh industrial environments including power supplies, automotive electronics, and consumer devices requiring efficient rectification solutions.
Measuring 4.5 mm in length, 2.79 mm in width, and 2.09 mm in height, the SS1H10-E3/61T mounting type is surface mount, facilitating automated assembly on PCBs for volume production. The diode configuration is single with 2 pins in the DO-214AC package type.
Maximum continuous forward current of 1 A ensures steady performance. Peak reverse repetitive voltage of 100 V provides effective blocking capability. Low maximum forward voltage of 0.62 V aids energy efficiency. Peak non-repetitive forward surge current of 50 A supports high transient loads.
Wide operating temperature range from -65°C to 175°C for versatile applications. Compact footprint helps reduce PCB space and weight. Single diode configuration ideal for rectification and power conversion. Surface mount DO-214AC package supports modern manufacturing methods.
High switching speed and low power loss enhance overall circuit performance.
This Schottky Diode is optimized for applications in industrial electronics, power and converter circuits, automotive electronics, and other semiconductor device requirements. It offers reliable performance even in demanding temperature and switching conditions, contributing to improved durability and efficiency of electrical systems.
Explore the Vishay range for advanced semiconductor components to meet various project specifications and industrial needs. EnvMart provides detailed product data for informed purchasing decisions in the electronics and electrical components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay SS1H10-E3/61T is 1 ampere.
This model has a peak reverse repetitive voltage rating of 100 volts, providing effective blocking capability.
The diode features a low forward voltage drop of 0.62 volts, which enhances energy efficiency.
The peak non-repetitive forward surge current for this diode is 50 amperes, supporting high transient loads.
It operates reliably across a wide temperature range from -65°C to 175°C, making it suitable for extreme conditions.
The diode is housed in a DO-214AC package type, which is suitable for surface mount assembly.
This model measures 4.5 mm in length, 2.79 mm in width, and 2.09 mm in height.
The SS1H10-E3/61T has a single diode configuration with 2 pins.
This diode is a Schottky rectifier, known for its fast switching and low forward voltage drop.
It is optimized for use in industrial electronics, power circuits, automotive electronics, and semiconductor applications.
The peak reverse current is rated at 1 microampere (1μA), indicating low leakage current.
This diode offers high performance with very fast switching action and low power loss, enhancing overall circuit efficiency.
