Otto P9 Series Push Button Switch Momentary Panel Mount DPDT White LED IP68 28V dc 115V ac P9-113129

Otto P9-113129 is a momentary push button switch from the Otto P9 Series, featuring a black body with a white dome-style actuator and white LED indicator. It is designed for panel mounting with a 0.5 inch cutout and offers a robust DPDT contact configuration suitable for controlling multiple circuits.

This switch is rated for 5 amps current and can operate on 28 V dc or 115 V ac, making it suitable for a variety of industrial applications including control grips, instruments, heavy machinery, and other automation systems.

With an IP68 rating, it provides excellent protection against dust and water ingress, ensuring durability and reliable operation in harsh environments. The unit withstands extreme shock and vibration while maintaining a low contact resistance for precise switching.

The switch's operating temperature range spans from -55°C to 85°C, supporting use in diverse climatic conditions. It features a dome actuator with a positive tactile feedback and a threaded body for secure panel mounting.

Mechanical life expectancy is approximately one million operations with an electrical life of 25,000 cycles at full rated load, reinforcing its reliability for long-term use. It complies with RoHS standards, ensuring environmental safety and non-toxicity.

Features a contoured dome style actuator in white color. Panel cutout size is 0.5 inch suitable for panel mounting. Double pole double throw (DPDT) contact configuration for versatile switching. Switch contact current rated at 5A with On-On configuration.

Enclosed design provides IP68 protection against dust and water ingress. Operating temperature range from -55°C to 85°C for harsh environments. Terminal type is solder for secure electrical connections. White LED indicator integrated for status signaling.

Designed for robust applications requiring approximately one million mechanical operations. Meets RoHS compliance standards indicating environmental safety.

This push button switch is ideal for use in industrial, electrical, automation, manufacturing, and control panels where rugged reliability and precise switching are key. The product assures long life and resilience while offering clear visual indication with its white LED.

For further selection of Push Button Switches and components, browse the Electronics & Electricals category at EnvMart.
