Otto P8 Series Push Button Switch, Momentary, Panel Mount, SPDT, Grey LED, IP64/IP68S/IP69K, 115 V AC, 10A P8-V316314
Specifications
| Country of Origin | India |
|---|---|
| Brand | Otto |
| Model | P8-V316314 |
| IP Rating | IP64, IP68S, IP69K |
| Mount Type | Panel |
| Series | P8 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Switch Configuration | On-On |
| Minimum Operating Temperature | -55°C |
| Terminal type | Solder |
| Standards/Approvals | CSA Certified, Reach Compliant, UL Recognized, UL1500, WEEE Compliant |
| LED Colour | Grey |
| Switch Operation | Momentary |
| Actuator Colour | Silver |
| Contact DC Voltage | 115V |
| Actuator Style | Push Button |
| Switch Contact Current | 10A |
| Contact AC Voltage | 115V ac |
Key Features
- The switch is housed in a stainless steel vandal resistant case and button.
- It provides positive tactile feedback with less than 25mΩ contact resistance.
- Rated for 115 V AC and DC voltages with a 10A contact current.
- Sealed terminals provide protection from solder flux and harsh environmental conditions.
- Mechanical life expectancy is 1,000,000 cycles ensuring long-term reliability.
- Operating temperature range from -55°C to 85°C.
- Complies with UL Recognized, CSA Certified, Reach Compliant, UL1500 ignition protected, and WEEE standards.
Product Description
Otto P8-V316314 is a high-quality, momentary push button switch designed for reliable panel mounting applications requiring robust and vandal resistant components. Featuring a stainless steel case and button, the switch ensures durability and protection in demanding industrial and public environments.
This SPDT (Single Pole Double Throw) switch is equipped with a grey LED actuator with a silver actuator color, complementing control panels and enhancing user interface clarity. The device offers ingress protection ratings of IP64, IP68S, and IP69K, making it suitable for wet and harsh environmental conditions.
The P8 series switch maintains high precision tactile feedback with contact resistance below 25mΩ. It supports 115 V AC and DC operation at a contact current rating of 10A. The sealed terminals provide additional protection from soldering flux and environmental contaminants, making it well-suited for rugged industrial applications.
With an operating temperature range of -55°C to 85°C, this push button is suitable for various climate conditions. The mechanical life expectancy of the switch is 1,000,000 cycles, ensuring extended service life in demanding setups.
Typical applications include door access security systems, public transport control, emergency telephones, traffic signals, process control environments, and other scenarios demanding durability, ruggedness, and security.
Stainless steel vandal resistant case for enhanced protection. IP64, IP68S, and IP69K rated for watertight sealing in harsh environments. Positive tactile feedback with low contact resistance of less than 25mΩ. Mechanical life expectancy up to 1 million cycles ensures long-lasting performance.
Compliance with UL Recognized, CSA Certified, Reach Compliant standards, and UL1500 ignition protection.
Choose Otto P8 Series Push Button Switches for durable, reliable control in industrial, transportation, security, and automation applications. Browse our comprehensive range on EnvMart for advanced electrical components and switches.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this switch is 85°C.
The contact current rating of the Otto P8-V316314 is 10A.
This model has ingress protection ratings of IP64, IP68S, and IP69K, making it suitable for wet and harsh environmental conditions.
The switch configuration is Single Pole Double Throw (SPDT).
The mechanical life expectancy of the Otto P8-V316314 is 1,000,000 cycles.
The minimum operating temperature for this switch is -55°C.
The Otto P8-V316314 features solder terminals for connection.
This model complies with CSA Certified, Reach Compliant, UL Recognized, UL1500, and WEEE standards.
The actuator color of this switch is silver, and it features a grey LED.
Typical applications include door access security systems, public transport control, emergency telephones, and traffic signals.
The contact voltage rating for this switch is 115V AC and DC.
The switch operation type is momentary, meaning it activates only while pressed.
