Texas Instruments Schmitt Trigger Input Schmitt Trigger Inverter 6 Elements 14-Pin TSSOP SN74LVC14APW

Texas Instruments SN74LVC14APW Schmitt Trigger Inverter 6 Elements 14-Pin TSSOP is a surface mount logic IC designed for efficient inverter applications requiring a Schmitt trigger input. It operates efficiently over a broad voltage range from 1.65V to 3.6V, providing reliable switching characteristics suitable for industrial, laboratory, and electronic manufacturing environments.

This inverter incorporates six individual Schmitt trigger elements per chip, optimized for CMOS push-pull output type, ensuring strong drive capability with a maximum high-level output current of -24mA and a low-level output current of 24mA. The device supports rapid signal processing with a maximum propagation delay time of 9.5 nanoseconds, enhancing performance in high-speed logic circuits.

The 14-pin TSSOP package supports surface mounting techniques, making it compatible with modern PCB assembly processes. Its operational temperature range from -40°C to 125°C ensures reliability in varying thermal conditions typical of industrial and commercial applications.

Compliant with RoHS directives, this component ensures reduced hazardous substance usage, aligning with environmental and safety standards. Manufactured in Malaysia, the SN74LVC14APW is part of the SN74LVC14A series belonging to the LVC logic family, making it an ideal choice for precision timing and signal conditioning in electronic assemblies.

6 integrated Schmitt trigger inverters with push-pull CMOS output. Wide supply voltage range from 1.65V minimum to 3.6V maximum. Fast switching speed with 9.5ns maximum propagation delay at specified load. Significant output current capabilities of -24mA high and 24mA low.

Surface mount 14-pin TSSOP package for compact PCB design. Robust device operation between -40°C and 125°C. RoHS compliant for environmental safety and regulatory adherence. Manufactured in Malaysia, ensuring quality and consistency.

This Schmitt trigger inverter IC serves as a critical component in industrial automation, signal processing circuits, laboratory instruments, and HVAC control systems where high-speed and noise-immune logic inversion is essential. These features make it suitable for integration into advanced electronic modules and custom PCB designs requiring reliable inverter functionality.
