Fujitsu Surface Signal Relay 18V Coil 1A DPDT RY-18W-K
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Fujitsu |
| Height | 12.5mm |
| Length | 20.2mm |
| Model | RY-18W-K |
| Width | 9.8mm |
| Mount Type | Surface |
| Contact Material | Silver Alloy |
| Series | RY |
| Maximum Operating Temperature | 90°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -30°C |
| Switching Current | 1A |
| Terminal type | Solder |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 1028Ω |
| Coil Voltage | 18V |
| Switching DC Voltage | 60V dc |
| Switching AC Voltage | 60V ac |
| Coil Power | 200mW |
| Switching Power | 24W |
Key Features
- Features a surface mount type for easy PCB integration.
- Supports switching AC/DC voltage up to 60V.
- Operates within a temperature range of -30°C to 90°C for wide environment tolerance.
- Constructed with silver alloy contacts ensuring high conductivity and durability.
- Has a coil power consumption of 200mW for efficient operation.
- Includes solder terminals for secure electrical connections.
- Contact resistance is low at 100mΩ ensuring minimal signal loss.
- Complies with RoHS standards ensuring environmental safety.
Product Description
Fujitsu RY-18W-K Surface Signal Relay offers industrial-grade signal switching with an 18V coil and a 1A switching current. Designed with a double pole double throw (DPDT) contact configuration, this relay suits a variety of electrical and automation applications requiring reliable signal control.
The surface mount design facilitates easy PCB assembly and integration into compact control systems. This relay supports switching voltages up to 60V for both AC and DC signals, making it versatile for low power industrial control circuits.
Operating temperatures from minus 30°C to 90°C allow it to perform reliably in harsh environments. Its silver alloy contacts ensure high conductivity and longevity, while the low contact resistance of 100mΩ minimizes energy losses and enhances signal integrity.
The coil consumes only 200mW at an 18V rating, balancing efficient power usage with performance. Solder type terminals provide secure connections suitable for automation and manufacturing equipment.
This relay complies with RoHS environmental restrictions, making it suitable for use in eco-conscious industrial setups. Its compact size of 20.2mm length, 12.5mm height, and 9.8mm width makes it ideal for space-constrained applications.
Features a surface mount design with a DPDT contact arrangement. Supports switching AC/DC voltages up to 60V and currents of 1A. Operates in wide temperature ranges suitable for industrial and commercial use. Utilizes silver alloy contacts and low resistance for reliable signal transmission.
Has a compact footprint, making it ideal for PCB mounting and automation systems. Coil power is optimized at 200mW for energy-efficient operation. Solder terminals ensure robust mechanical and electrical connections. Complies with RoHS directives for environmental safety.
Manufactured in Japan, ensuring stringent quality control. Includes surge strength of 1,500 V enhancing reliability in responsive circuits.
Ideal for industrial automation, electronic controls, signal conditioning, manufacturing environments, and other electrical applications requiring dependable signal relays. Explore a wide selection of Signal Relays and electrical components in the EnvMart catalog.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a double pole double throw (DPDT) contact configuration, allowing it to control multiple circuits simultaneously.
It supports switching voltages up to 60V for both AC and DC signals, making it versatile for various applications.
The relay operates with an 18V coil and has a coil power consumption of 200mW, ensuring efficient operation.
It operates within a temperature range of -30°C to 90°C, suitable for a variety of environments.
The contact resistance is low at 100mΩ, which minimizes signal loss and enhances signal integrity.
It includes solder terminals, providing secure electrical connections suitable for automation and manufacturing equipment.
The dimensions are 20.2mm in length, 12.5mm in height, and 9.8mm in width, making it compact for PCB mounting.
The contacts are constructed with silver alloy, ensuring high conductivity and durability.
Yes, it complies with RoHS standards, ensuring it meets environmental safety requirements.
The maximum switching current is 1A, suitable for low power industrial control circuits.
It is manufactured in Japan, ensuring stringent quality control during production.
The relay has a surge strength of 1,500 V, enhancing its reliability in responsive circuits.
