Arcolectric (Bulgin) Ltd Illuminated Push Button Switch Latching Panel Mount DPDT 16.2 mm Cutout Red LED MP0045
Specifications
| Country of Origin | China |
|---|---|
| Brand | Arcolectric (Bulgin) Ltd |
| Model | MP0045 |
| IP Rating | IP67 |
| Mount Type | Panel |
| Series | MP0045/1E1 |
| Maximum Operating Temperature | 55°C |
| Contact Configuration | DPDT |
| Switch Configuration | DPCO |
| Minimum Operating Temperature | -20°C |
| Panel Cutout Size | 16.2 mm |
| Terminal type | Solder Tag |
| Standards/Approvals | RoHS |
| LED Colour | Red |
| Switch Operation | Latching |
| Actuator Colour | Silver |
| Contact DC Voltage | 250V |
| Actuator Style | Round |
| Switch Contact Current | 3A |
| Contact AC Voltage | 250V ac |
| Legend | Blank |
Key Features
- This panel mount switch requires a 16.2 mm cutout for installation.
- The DPDT contact configuration supports versatile dual pole double throw switching.
- Equipped with a red illuminated LED for clear visibility.
- Designed for operation between -20°C and 55°C with IP67 rated protection against dust and water.
- Durable brass contacts provide reliable current handling up to 3A at 250V AC/DC.
- The actuator is round-shaped and silver-colored for ergonomic use and aesthetic appeal.
- Solder tag terminals enable straightforward wiring during assembly.
Product Description
Arcolectric (Bulgin) Ltd MP0045/1E1RD012S illuminated push button switch is engineered for panel mounting with a precise 16.2 mm cutout size. This latching switch maintains its ON or OFF position, making it highly suitable for industrial and automation control applications.
The switch features a dual pole double throw (DPDT) contact configuration allowing multiple circuit control capabilities. Its round actuator, finished in silver, incorporates a red LED for enhanced user feedback through illumination.
Constructed for harsh environments, this switch is IP67 rated, ensuring complete dust ingress protection and water immersion resistance up to 1 meter for 30 minutes. It operates reliably over a temperature range from -20°C to 55°C, suitable for diverse industrial settings.
Brass contact materials are incorporated to deliver excellent conductivity and durability, with contact ratings of 3A under 250V AC and DC voltage conditions. The mounting style is panel type, and solder tag terminals facilitate secure electrical connections.
Applications of this illuminated push button switch include use in industrial machinery controls, electrical panels requiring visible indication, and automated system interfaces demanding reliable latching functionality. Its rugged construction and versatile electrical configuration support use in manufacturing, commercial, and automation industries.
This switch provides IP67-rated dust and water protection ensuring durability in challenging environments. Brass contacts ensure stable electrical connectivity and long service life. Latching operation benefits include maintaining switch state without continuous actuation.
Wide operating temperature range enables deployment in varied climate conditions. DPDT switching configuration supports complex circuit control requirements. Red LED illumination serves as a clear visual indicator of the switch state.
Easy panel installation with round actuator and precise cutout dimensions. Explore more quality Push Button Switches and components on EnvMart for your industrial and electrical control needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This illuminated push button switch requires a cutout size of 16.2 mm for panel mounting.
It features a dual pole double throw (DPDT) contact configuration, allowing for versatile circuit control.
The switch operates reliably within a temperature range of -20°C to 55°C.
This model has an IP67 rating, providing complete protection against dust and water immersion up to 1 meter for 30 minutes.
The switch can handle a contact current of up to 3A at 250V AC/DC.
It is equipped with solder tag terminals, which facilitate straightforward wiring during assembly.
The switch features a red LED for enhanced visibility and user feedback.
The actuator is round in style and finished in silver, providing both ergonomic use and aesthetic appeal.
This model complies with RoHS standards, ensuring it meets environmental regulations.
It is suitable for use in industrial machinery controls, electrical panels, and automated system interfaces requiring reliable latching functionality.
The switch belongs to the MP0045/1E1 series, which includes various configurations of illuminated push button switches.
The latching operation allows the switch to maintain its ON or OFF position without continuous actuation, enhancing usability in control applications.
