Schneider Electric Harmony Series Push Button Switch Spring Return Panel Mount 30 mm Cutout SPST Black LED IP69 XB5FA3351
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Height | 55mm |
| Length | 42mm |
| Model | XB5FA3351 |
| IP Rating | IP69 |
| Width | 36.6mm |
| Mount Type | Panel |
| Series | Harmony |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Switch Configuration | 1 NO |
| Minimum Operating Temperature | -40°C |
| Panel Cutout Size | 30 mm |
| Terminal type | Screw |
| LED Colour | Black |
| Switch Operation | Spring Return |
| Actuator Colour | Black |
| Contact DC Voltage | 600V |
| Actuator Style | Round |
| Switch Contact Current | 6A |
| Better World Claim | Repairable by the End User |
| Legend | Symbol |
| Various types of connection are available | screw clamp, connector, Faston connector, spring terminal, or printed circuit board |
| General purpose offer covering all segments and applications | Industry |
| Ideal in extreme environments | food and beverage, marine, etc. Building and infrastructure |
Key Features
- Features a 30 mm cutout size for flush mounting in control panels.
- Single Pole Single Throw (SPST) contact configuration with 1 NO slow break contact.
- Equipped with a black LED actuator and black round head for clear indication.
- High ingress protection rating of IP69 ensures resistance against dust and high-pressure water jets.
- Operates at contact voltages up to 600 V AC/DC with a switch contact current rating of 6 A.
- Includes robust screw terminal type for secure electrical connections.
- Designed to withstand temperatures ranging from -40°C to 70°C for extreme environment use.
- Complies with multiple international standards including EN/IEC 60947 and UL 508 for reliability and safety.
Product Description
Schneider Electric XB5FA3351 Harmony Series Push Button Switch is a high-quality, spring return push button designed for panel mounting applications. With a 30 mm panel cutout, it provides a robust and ergonomic solution for controlling industrial machinery and automation systems.
Featuring a single pole single throw (SPST) 1 NO slow break contact, this switch handles up to 600 V AC/DC contact voltage and a 6 A contact current, suitable for general industrial use. Its black LED actuator and black round flush push head offer clear operational feedback and aesthetic appeal.
The switch is built to endure harsh environments with an IP69 ingress protection rating, guaranteeing resistance against dust, water jets, and shock, making it ideal for food and beverage, marine, and chemical environments.
Operating over a temperature range from -40°C to 70°C, it withstands extreme conditions while maintaining performance. The screw terminal type ensures secure wiring connections, complemented by vibration-resistant design with shake-proof screws for reliable operation in industrial settings.
Certified under international standards such as EN/IEC 60947 series, UL 508, CSA C22.2 No 14, JIS C8201, CE marking, and ISO standards, this push button switch meets stringent safety and performance requirements.
Features a 30 mm panel cutout for easy installation. Single Pole Single Throw (SPST) 1 NO contact configuration. Flush mount black round actuator with black LED. IP69 rated for dust and water resistance. Contact voltage rating of 600 V AC/DC and 6 A current rating.
Robust screw clamp terminals with vibration resistance. Operating temperature from -40°C to 70°C. Compliant with multiple international certifications. Lightweight design at 37 grams and compact dimensions. Antimicrobial characteristics for hygienic applications.
The packaging includes one unit of the Schneider Electric XB5FA3351 push button switch, ready for panel installation with common tools. Accessories can be ordered separately for customization needs. Due to its reliability, durability, and industry certifications, this switch is suitable for a broad range of industrial sectors including manufacturing, automation, food processing, marine, and building infrastructure.
Explore more Schneider Electric products and Push Button Switch options on EnvMart for comprehensive electrical automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a Single Pole Single Throw (SPST) contact configuration with 1 Normally Open (NO) slow break contact.
It has an ingress protection rating of IP69, ensuring resistance against dust and high-pressure water jets.
The maximum operating temperature for this switch is 70°C, making it suitable for use in extreme environments.
It operates at contact voltages up to 600 V AC/DC with a switch contact current rating of 6 A.
The required panel cutout size for this push button switch is 30 mm.
This unit includes robust screw terminals for secure electrical connections.
This push button switch weighs 37 grams, contributing to its lightweight design.
The minimum operating temperature for this model is -40°C, allowing it to function in very cold environments.
It is ideal for use in food and beverage, marine, and chemical environments due to its robust design and IP69 rating.
This switch complies with multiple international standards including EN/IEC 60947, UL 508, and CE marking.
The actuator style is round, and it features a black color, providing clear operational feedback.
Yes, it is designed to be repairable by the end user, which is part of its sustainability features.
