ITW Switches Illuminated Miniature Push Button Switch, Momentary, Panel Mount, 13.6 mm Cutout, SPST, Green LED 59-412G
Specifications
| Country of Origin | Belize |
|---|---|
| Brand | ITW Switches |
| Model | 59-412G |
| IP Rating | IP67 |
| Mount Type | Panel |
| Series | 59 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Switch Configuration | On-Off |
| Minimum Operating Temperature | -35°C |
| Panel Cutout Size | 13.6 mm |
| Terminal type | Solder |
| Standards/Approvals | UL, CSA |
| LED Colour | Green |
| Switch Operation | Momentary |
| Actuator Colour | Red |
| Contact DC Voltage | 125V |
| Actuator Style | Dome |
| Switch Contact Current | 400mA |
| Contact AC Voltage | 125V ac |
Key Features
- This switch operates on a momentary push button mechanism.
- It features an SPST contact configuration suitable for on-off switch applications.
- The actuator color is red with a dome style, incorporating illumination via green LED.
- Panel mounting type with a precise cutout size of 13.6 mm ensures ease of installation.
- It is rated IP67 for dust tightness and water immersion protection.
- Supports contact voltages of 125 V AC and DC with a switch contact current of 400 mA.
- The switch has UL and CSA certifications, ensuring safety and compliance.
- Designed to operate between temperatures of -35°C to 85°C for rugged industrial environments.
Product Description
ITW Switches 59-412G is a high-quality illuminated miniature push button switch designed for momentary operation. With a panel mount type and a 13.6 mm cutout, it is suitable for precise installation in compact control panels.
This switch features a red dome-style actuator with integrated green LED illumination, enhancing visual indication in industrial and commercial applications. It offers a single-pole single-throw (SPST) switch configuration, providing reliable on-off control for circuits up to 125 V AC/DC and 400 mA current rating.
Rated at IP67, this switch is dust-tight and resistant to temporary water immersion, making it ideal for use in harsh environments such as military, communications, instrumentation, mass transport controls, and environmentally demanding keypads.
Constructed with robust materials including gold contacts, the switch ensures longevity and dependable connectivity under challenging conditions. Operating temperature ranges from -35°C to 85°C accommodate wide environmental tolerance for industrial and laboratory applications.
The 59 series from ITW Switches offers rugged panel sealing and impact resistance, meeting UL and CSA standards. These features make it especially suitable for applications requiring sealing against dust and moisture along with sturdy mechanical performance.
This model is a sealed, high-reliability pushbutton switch designed for industrial and commercial electrical control panels. Illumination with green LED improves operator feedback and status monitoring. Gold contacts ensure superior electrical performance and corrosion resistance.
Compliant with international safety standards including UL and CSA. IP67 rating guarantees protection against dust ingress and water exposure. Momentary switch operation is ideal for temporary activation applications. Robust design resists impact and environmental hazards.
Suitable for communications, military, instrumentation, and mass transport controls. Easy panel mount installation with standard 13.6 mm cutout dimensions. Versatile temperature range accommodates diverse climatic conditions.
This ITW Switches 59-412G miniature push button switch provides a dependable solution for sophisticated control systems requiring illuminated feedback and environmental robustness. Browse more ITW Switches products and similar Push Button Switches on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a single-pole single-throw (SPST) contact configuration suitable for on-off switch applications.
The maximum operating temperature for this switch is 85°C.
It requires a panel cutout size of 13.6 mm for installation.
The switch is rated IP67, indicating it is dust-tight and resistant to temporary water immersion.
It features a green LED illumination for enhanced visual indication.
The switch supports contact voltages of 125 V AC and 125 V DC.
The switch has a contact current rating of 400 mA.
The actuator style is dome, and the actuator color is red.
It has UL and CSA certifications, ensuring compliance with safety standards.
The minimum operating temperature for this switch is -35°C.
This switch operates on a momentary push button mechanism.
The terminal type for this model is solder.
