DiodesZetex Transistor 500 mA PNP Bipolar, 300 V, 3-Pin SOT-23 Package MMBTA92-7-F

DiodesZetex MMBTA92-7-F is a robust PNP bipolar transistor designed for surface-mount applications with a compact 3-pin SOT-23 package. Rated for a maximum DC collector current of 500 mA and a collector-emitter voltage of 300 V, it is suitable for various electronic and power management circuits.

Featuring a maximum power dissipation of 300 mW and a minimum DC current gain of 25, this transistor ensures effective switching and amplification performance. It operates reliably over a wide temperature range of -55°C to 150°C, making it suitable for industrial, automotive, and consumer electronics applications.

The device’s small package size (3 mm length, 2.5 mm width, and 1.1 mm height) facilitates compact PCB layouts and efficient surface mounting. The transistor’s maximum collector-base voltage and emitter-base voltage ratings are both -300 V and -5 V respectively, providing ample margin for high voltage uses.

MMBTA92-7-F complies with the automotive standard AEC-Q101, confirming its suitability for automotive environments requiring high-quality components. This transistor is commonly used in power management, amplification, and switching applications across telecommunications, HVAC, instrumentation, and manufacturing industries.

This transistor supports a maximum power dissipation of 300 mW. The gain (hFE) minimum is specified at 25 for reliable amplification. It operates over a temperature range of -55°C to 150°C for robust performance. The package dimensions are compact at 3 mm length, 2.5 mm width, and 1.1 mm height.

This device complies with the automotive standard AEC-Q101, ensuring high reliability. Explore more semiconductor transistors and discrete components in our industrial catalog for your electronics design needs.
