Molex Micro-Lock Plus Series Straight Surface PCB Header, 6 Contacts, 1.25 mm Pitch, 1 Row, Shrouded 505568-0671

Free Delivery in India | Lowest Global Shipping Charges

Molex Micro-Lock Plus Series Straight Surface PCB Header, 6 Contacts, 1.25 mm Pitch, 1 Row, Shrouded 505568-0671

Name: Molex Micro-Lock Plus Series Straight Surface PCB Header, 6 Contacts, 1.25 mm Pitch, 1 Row, Shrouded 505568-0671
Brand: Molex
SKU: 217574
Price: 1.04 USD
Availability: InStock



Category PCB Connectors & Wire Housings Brand Molex Condition New

Specifications

Country of Origin	Malaysia
Voltage	50V
Brand	Molex
Orientation	Straight
Current	1.5A
Mount Type	Surface
Housing Material	Polyamide
Contact Material	Brass
Series	Micro-Lock Plus
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	1.25mm
Contact Plating	Tin
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Features a robust polyamide housing for durability and insulation.
Brass male contacts plated with tin for corrosion resistance.
Designed for surface mounting and solder termination.
Operates safely between -40°C to 105°C temperature range.
Supports continuous current up to 1.5 A and voltage rating of 50 V.
Compact 1.25 mm pitch accommodates high-density PCB designs.
Color-coded for easy assembly and identification.
Suitable for automotive and industrial applications requiring high temperature and reliability.

Product Description

Molex 505568-0671 Micro-Lock Plus Series Straight Surface PCB Header is engineered for high-reliability wire-to-board connections with a compact 1.25 mm pitch and 6 male brass contacts plated with tin. The shrouded design and polyamide housing provide mechanical strength and electrical insulation critical for automotive, industrial automation, and consumer electronics.

This single-row connector supports current ratings of 1.5 A and voltages up to 50 V, withstanding operating temperatures from -40°C to 105°C. It uses surface mount technology with solder terminations enhancing PCB assembly efficiency.

Applications include steering wheel assemblies, paddle shifters, combination switches in automotive sectors; also suitable for white goods, drones, air conditioners, laser printers, and vacuum cleaners in consumer electronics.

The connector system promotes error-free assembly via color coding, meeting industry demands for compact, reliable connectors that resist harsh environments. Polyamide housing ensures durability and electrical isolation.

Brass contact material with tin plating for corrosion resistance and conductivity. Surface mount solder termination enhances connection reliability. Wide temperature range supports automotive-grade applications. Compact pitch supports high-density PCB designs.

Shrouded single-row configuration protects contacts from damage. Wire-to-board connector system optimized for mechanical and electrical reliability. Versatile use in industrial, automotive, and consumer applications. Explore EnvMart's comprehensive range of advanced PCB connectors for your electronics manufacturing and prototyping needs.
