DiodesZetex 80 V 500 mA General Purpose 6-Pin Surface Mount Diode SOT-363 MMBD4448HTW-7-F
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1mm |
| Length | 2.2mm |
| Model | MMBD4448HTW-7-F |
| Width | 1.35mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-363 (SC-88) |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | FBI |
| Pin Count | 6 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 500mA |
| Peak Reverse Repetitive Voltage Vrrm | 80V |
| Diode Configuration | Isolated |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 50μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 4A |
| Maximum Forward Voltage Vf | 1.25V |
| Peak Reverse Recovery Time trr | 4ns |
Key Features
- Operates efficiently at temperatures from -65°C to 150°C.
- Designed for fast switching with a reverse recovery time of 4 nanoseconds.
- Supports peak non-repetitive forward surge current of up to 4 A.
- Features an isolated diode configuration with low peak reverse current of 50 microamps.
- Compact package dimensions of 2.2 mm length, 1.35 mm width, and 1 mm height.
- Meets automotive standard AEC-Q101 for reliability in automotive applications.
- Maximum forward voltage drop of 1.25 V ensures energy efficiency.
- Suitable for electronic circuit applications requiring high switching speed and low power loss.
Product Description
DiodesZetex MMBD4448HTW-7-F is a high-quality general purpose diode designed for surface mounting in electronic circuits. It features a 6-pin SOT-363 package (also known as SC-88) making it compact and suitable for densely packed PCB layouts.
The diode has a maximum continuous forward current of 500 mA and can withstand a peak reverse repetitive voltage of 80 V. This makes it well-suited for a variety of semiconductor switching applications.
Operating in extreme temperature ranges from -65°C to 150°C, this diode is ideal for use in automotive and industrial environments. Its fast switching capabilities are supported by a peak reverse recovery time of only 4 nanoseconds, enabling efficient performance in rapid switching power circuits.
Additional features include a peak non-repetitive forward surge current capacity of 4 A, a low peak reverse current of 50 µA, and an isolated diode configuration that aids in reliable switching operations. The maximum forward voltage drop of 1.25 V helps minimize power losses.
Compact surface mount design in SOT-363 package enhances PCB space utilization. Complies with automotive industry standard AEC-Q101, ensuring high reliability. Ideal for use in power management, switching, and general electronic diode applications.
Package dimensions: length 2.2 mm, width 1.35 mm, height 1 mm. Wide operating temperature range supports diverse environmental conditions.
This diode is extensively used in industrial electronics, automotive electronics, telecommunications, and consumer electronic products. Its reliable performance and compact size make it a preferred choice for designers aiming for efficient and space-saving circuit designs.
Explore further DiodesZetex semiconductors and components on EnvMart to find complementary products for your electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the MMBD4448HTW-7-F diode is 500 mA.
This model can withstand a peak reverse repetitive voltage of 80 V.
The package dimensions are 2.2 mm in length, 1.35 mm in width, and 1 mm in height.
The diode supports a peak non-repetitive forward surge current of up to 4 A.
It has a fast reverse recovery time of 4 nanoseconds.
The diode operates efficiently at temperatures ranging from -65°C to 150°C.
The maximum forward voltage drop of this diode is 1.25 V.
This model features a low peak reverse current of 50 microamps (50 µA).
Yes, it meets the automotive standard AEC-Q101 for reliability in automotive applications.
The diode has an isolated configuration, which aids in reliable switching operations.
It is extensively used in industrial electronics, automotive electronics, telecommunications, and consumer electronic products.
The MMBD4448HTW-7-F features a pin count of 6.
