HARWIN Datamate L-Tek Series Straight Through Hole PCB Header 6 Contacts 2 mm Pitch 2 Row Shrouded M80-8670622

Free Delivery in India | Lowest Global Shipping Charges

HARWIN Datamate L-Tek Series Straight Through Hole PCB Header 6 Contacts 2 mm Pitch 2 Row Shrouded M80-8670622

Name: HARWIN Datamate L-Tek Series Straight Through Hole PCB Header 6 Contacts 2 mm Pitch 2 Row Shrouded M80-8670622
Brand: HARWIN
SKU: 217185
Price: 3.76 USD
Availability: InStock



Category PCB Header Brand HARWIN Condition New

Specifications

Country of Origin	United Kingdom
Voltage	1.2kV
Brand	HARWIN
Orientation	Straight
Current	3A
Model	M80-8670622
Mount Type	Through Hole
Housing Material	Polyphenylene Sulphide
Contact Material	Phosphor Bronze
Series	Datamate L-Tek
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2mm
Contact Plating	Gold
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board
Tail Pin Length	3mm

Key Features

This PCB header features a 2 mm pitch and double row configuration for robust board-to-board and wire-to-board connections.
The housing is made of durable Polyphenylene Sulphide ensuring excellent mechanical and temperature resistance.
Phosphor bronze contacts are gold plated providing reliable conductivity and corrosion resistance.
Supports a current capacity of 3 A and a voltage rating of 1.2 kV for demanding electronic applications.
Shrouded design with locking latches ensures secure mating; tooling required for separation.
Operating temperature ranges from -55°C to 125°C, suitable for industrial and commercial use.
Tail pin length is 3 mm with straight, male contact orientation optimized for solder termination.
Manufactured in the United Kingdom maintaining high quality standards.

Product Description

HARWIN M80-8670622 Datamate L-Tek Series Straight Through Hole PCB Header is engineered for reliable electronic interconnections in industrial, laboratory, and commercial applications. Designed with 6 gold-plated phosphor bronze contacts arranged in two rows with a 2 mm pitch, this connector offers stable electrical performance and durability.

The header features a shrouded housing made from high-quality Polyphenylene Sulphide, known for its heat resistance and mechanical strength. It supports up to 3 A current and withstands voltages up to 1.2 kV, making it suitable for power and signal transmission tasks.

Its through-hole mounting type ensures a secure and robust mechanical connection to printed circuit boards, while the straight male contacts with 3 mm tail pins facilitate easy soldering. The shrouded design includes locking latches to prevent accidental disconnection, enhancing connection reliability in vibration-prone or high-demand industrial environments.

The operating temperature range from -55°C to 125°C allows this PCB header to function efficiently in harsh environments including automation, manufacturing equipment, and control systems.

Double row, 6 contacts (3+3) with gold plating on contact areas for excellent conductivity. High-temperature resistant Polyphenylene Sulphide housing material for longevity. Locking latches provide secure connector mating; separation requires tooling for safety.

Suitable for board-to-board and wire-to-board connections in electronic devices. Robust design meets demanding industrial and laboratory application requirements.

HARWIN is well recognized for its quality electronic components. Explore similar connectors and electronic components in the EnvMart PCB Headers category to meet diverse engineering needs.
