Samtec TSW Series Straight Through Hole Pin Header, 40 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-120-07-T-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSW Series Straight Through Hole Pin Header, 40 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-120-07-T-D

Name: Samtec TSW Series Straight Through Hole Pin Header, 40 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-120-07-T-D
Brand: Samtec
SKU: 216985
Price: 2.72 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	Malaysia
Voltage	465V
Brand	Samtec
Orientation	Straight
Current	4.7A
Model	TSW-120-07-T-D
Mount Type	Through Hole
Special Features	Many options for optimizing cost and performance with platings and ruggedizing features
Housing Material	Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	TSW
Termination	Through-hole
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	40
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board, Wire-to-Board
Contact System	.025" (0.635 mm) square post

Key Features

Features 40 male contacts suitable for board-to-board and wire-to-board connections.
Constructed with glass filled polyester housing for enhanced durability.
Operates reliably within temperature range of -55°C to 125°C.
Contact system consists of .025" (0.635 mm) square post pins with tin plating.
Designed for through-hole mount with solder termination for secure attachment.
Rated for 4.7A current and 465V voltage to handle demanding electronic applications.
Unshrouded design allows flexibility in PCB layouts and wiring configurations.
Manufactured in Malaysia ensuring quality and precision standards.

Product Description

Samtec TSW-120-07-T-D is a high-quality straight through-hole pin header featuring 40 male contacts arranged in 2 rows with a standard 2.54 mm pitch. This unshrouded connector is designed to provide reliable board-to-board or wire-to-board connections in a variety of electronic applications including industrial, commercial, and manufacturing electronics assemblies.

The housing is made from durable glass filled polyester, ensuring good mechanical strength and resistance to environmental factors. The pins are made from phosphor bronze with tin plating, providing excellent conductivity and corrosion resistance.

Operating temperature capability ranges from -55°C to 125°C, making it suitable for demanding environments. The connector is rated for a maximum current of 4.7A and voltage up to 465V, ensuring safe and efficient performance in power and signal transmission.

The termination type is solder through-hole, facilitating secure and stable PCB mounting. The unshrouded design offers design flexibility and easy access for connection and maintenance.

This product is an Extended Life Product™ with long-lasting performance characteristics, suitable for industrial electronics, instrumentation, and communications equipment. Manufactured in Malaysia, it meets rigorous quality standards.

Features 40 male contacts suitable for board-to-board and wire-to-board connections. Constructed with glass filled polyester housing for enhanced durability. Operates reliably within temperature range of -55°C to 125°C. Contact system consists of .025" (0.635 mm) square post pins with tin plating.

Designed for through-hole mount with solder termination for secure attachment. Rated for 4.7A current and 465V voltage to handle demanding electronic applications. Unshrouded design allows flexibility in PCB layouts and wiring configurations.

Manufactured in Malaysia ensuring quality and precision standards.

This pin header is widely used in electronic circuits across industrial, manufacturing, and commercial sectors for reliable interconnect solutions. Browse EnvMart for more Samtec connectors and electronics components.

Explore more products in our PCB Header category.
