Samtec TSW Series Straight Through Hole Pin Header, 10 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-105-07-T-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 465V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.7A |
| Model | TSW-105-07-T-D |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- High current rating of 4.7A for reliable electrical performance.
- Housing constructed from durable glass filled polyester material.
- Phosphor bronze contacts with tin plating ensure corrosion resistance.
- Through-hole solder termination for secure mounting.
- Operating temperature range from -55°C to 125°C supports demanding environments.
- Unshrouded straight orientation allows easy mating with connectors.
- Extends product life with high mating cycles and Mixed Flowing Gas resistance.
Product Description
Samtec TSW-105-07-T-D is a high-quality PCB Pin Header designed for electronic components requiring board-to-board and wire-to-board connections. This through-hole type pin header is constructed with 10 pins arranged in 2 rows at a pitch of 2.54 mm. The unshrouded and straight orientation allows for straightforward mating with compatible connectors.
The housing is made from glass filled polyester, offering excellent durability and thermal stability. Phosphor bronze contacts are plated with tin, providing excellent corrosion resistance and conductivity. This connector supports a high current rating of 4.7A and a voltage rating of 465V, making it suitable for various industrial and commercial electronic applications.
It operates reliably in harsh environments with a temperature tolerance of -55°C to 125°C. This Extended Life Product™ is engineered to withstand up to 10 years of Mixed Flowing Gas exposure and sustain 250 to 2,500 mating cycles, ensuring long-term durability and performance.
Termination is through-hole solder type, providing secure and robust mechanical and electrical connections on printed circuit boards. Many options exist within the TSW series for different pin counts, row configurations, and plating options to optimize cost and performance.
High current rating of 4.7A. Durable glass filled polyester housing. Corrosion-resistant phosphor bronze contacts with tin plating. Through-hole solder termination type. Wide operating temperature range from -55°C to 125°C.
Unshrouded design with straight orientation. Voltage rating up to 465V. Extended life with high mating cycle capability.
This pin header is well suited for use in industrial electronics, instrumentation, communications, manufacturing equipment, and other demanding environments requiring reliable PCB connectivity solutions. For more options, browse the PCB Pin Header category at EnvMart for compatible connectors and PCB components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a high current rating of 4.7A, ensuring reliable electrical performance.
The voltage rating for this pin header is 465V, making it suitable for various applications.
The housing is made from glass filled polyester, while the contacts are phosphor bronze with tin plating for corrosion resistance.
It operates reliably within a temperature range of -55°C to 125°C, suitable for demanding environments.
This pin header features 10 contacts arranged in 2 rows.
It uses a through-hole solder termination type for secure mounting on printed circuit boards.
The pitch of the contacts is 2.54 mm, facilitating standard PCB layouts.
The TSW-105-07-T-D features a straight orientation, allowing for easy mating with compatible connectors.
It is well suited for industrial electronics, instrumentation, communications, and manufacturing equipment.
This connector is designed to withstand between 250 to 2,500 mating cycles, extending its product life.
The TSW-105-07-T-D is an unshrouded pin header, which allows for straightforward mating with connectors.
The country of origin for this pin header is India.
