Samtec PCB Header Right Angle Through Hole, 4 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 954V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 3.8A |
| Model | IPL1 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | IPL1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Right angle orientation supports board-to-wire connections.
- Shrouded connector design ensures protection and polarity prevention.
- Phosphor bronze contacts plated with gold for reliable conductivity.
- Current rated up to 3.8A at 95°C operating temperature.
- Constructed with liquid crystal polymer housing material for durability.
- Through hole mount type for stable PCB installation.
- Operates between -55°C to 125°C temperature range.
- 2 row contact arrangement with 2.54 mm row pitch for compact design.
Product Description
Samtec IPL1 series Right Angle Through Hole PCB Header, model IPL1, features 4 contacts aligned in 2 rows with a 2.54 mm pitch, designed for reliable wire-to-board connections in industrial and electronic applications. It utilizes a shrouded housing made from liquid crystal polymer, providing mechanical protection and ensuring correct mating orientation.
This PCB header employs phosphor bronze contacts plated with gold to ensure low electrical resistance and excellent signal integrity. The connector supports a current rating of 3.8 amperes at 95°C with voltage tolerance up to 954 volts, making it suitable for robust industrial electronics, control panels, and communication equipment.
The product is designed for through hole mounting to provide durable physical connection on printed circuit boards. It operates reliably within a temperature range from -55°C to 125°C, suitable for varied environmental conditions.
Right angle orientation for efficient PCB layout and wire routing. Shrouded contacts reduce risks of misconnection and provide protection. High-quality gold plating ensures corrosion resistance and optimal conductivity. Liquid crystal polymer housing offers mechanical strength and thermal stability.
Compatible with standard 2.54 mm pitch spacing for easy integration. Suitable for industrial, electronic component assembly, and manufacturing sectors. Manufactured in the United States ensuring strict quality standards.
This Samtec IPL1 series PCB Header is engineered for precision and durability in demanding electronic assemblies. For more options, browse EnvMart’s comprehensive PCB Headers and connectors categories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3.8A at an operating temperature of 95°C.
It has a voltage tolerance of up to 954 volts, making it suitable for various industrial applications.
This model operates reliably within a temperature range of -55°C to 125°C.
It is designed for through hole mounting, ensuring a stable installation on printed circuit boards.
The housing is constructed from liquid crystal polymer, providing mechanical strength and thermal stability.
This model features 4 contacts arranged in 2 rows with a 2.54 mm pitch.
The contacts are plated with gold, which ensures low electrical resistance and excellent signal integrity.
It has a right angle orientation, which supports efficient board-to-wire connections.
The contacts are made from phosphor bronze, which contributes to reliable conductivity.
It employs a wire-to-board connector system, suitable for various electronic applications.
This PCB header is manufactured in the United States, ensuring adherence to strict quality standards.
It uses a solder termination type for secure connections.
