Preci-Dip 811 Series Straight Surface Spring Loaded Connector, 5 Contacts, 2.54 mm Pitch, 1 Row 811-SS-005-30-003191

Preci-Dip 811-SS-005-30-003191 Spring Loaded Connector is a high-quality PCB header designed for reliable electrical connections in industrial and electronic applications. Featuring 5 spring-loaded contacts arranged in a single row with 2.54 mm pitch, this connector is ideal for automated machinery, instrumentation, communication devices, and other precision electronic equipment.

The straight orientation with a shrouded mounting ensures secure and stable mechanical and electrical connections, minimizing the risk of damage or disconnection during vibration or movement. Its brass contact material with gold plating guarantees excellent conductivity and long-term reliability, while the fibreglass reinforced polyethylene terephthalate housing provides thermal and mechanical stability over a broad temperature range from -55°C to 125°C.

This connector supports a current rating of 3.5A and is suitable for low voltage applications up to 150V. The solder termination type facilitates easy mounting to PCB surfaces in surface mount pad configurations. The spring-loaded contact design allows for low resistance and continuous electrical contact even under mechanical stress, reducing micro-discontinuities and noise.

Spring-loaded contacts ensure consistent electrical performance under vibration. Shrouded housing protects contacts and improves connector durability. High quality gold-plated brass contacts provide excellent conductivity.

Robust fibreglass reinforced housing withstands industrial temperature extremes. Surface mount design compatible with automated PCB assembly. Operates reliably between -55°C and 125°C. Supports 3.5 amperes current at 150 volts maximum rating.

Male contact gender with solder termination for reliable mounting.

This Preci-Dip spring loaded connector series is an excellent choice for demanding electronic equipment requiring robust, low resistance interface connectors. Widely used across manufacturing, instrumentation, laboratory, telecommunications, and industrial automation sectors. For alternative mounting options, please explore the available counterpart SMD SIL Pad Connectors.
