Preci-Dip Spring Loaded Connector 811 Series Straight Through Hole, 6 Contacts, 2.54 mm Pitch, 1 Row 811-S1-006-10-016101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip Spring Loaded Connector 811 Series Straight Through Hole, 6 Contacts, 2.54 mm Pitch, 1 Row 811-S1-006-10-016101

Name: Preci-Dip Spring Loaded Connector 811 Series Straight Through Hole, 6 Contacts, 2.54 mm Pitch, 1 Row 811-S1-006-10-016101
Brand: Preci-Dip
SKU: 215267
Price: 7.6 USD
Availability: InStock



Category PCB Connectors Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	3.5A
Model	811-S1-006-10-016101
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Series	811
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

The connector features straight through hole mounting for secure PCB installation.
6 gold-plated brass contacts ensure stable and low resistance electrical connections.
The housing is made from fibreglass reinforced polyethylene terephthalate providing robust insulation.
Shrouded design offers protection and guides proper mating with counterparts.
Supports current rating up to 3.5 A and voltage rating of 150 V suitable for various electronic applications.
Operates reliably within a temperature range from -55°C to 125°C.
Contact gender is male, compatible with corresponding female connectors.
Ideal for industrial, electronic manufacturing, and PCB assembly environments.

Product Description

Preci-Dip 811-S1-006-10-016101 Spring Loaded Connector offers 6 male contacts arranged in a single row with a 2.54 mm pitch, designed for straight through hole mounting on printed circuit boards (PCBs). This shrouded connector features a durable housing constructed from fibreglass reinforced polyethylene terephthalate, ensuring excellent electrical insulation and mechanical strength.

The gold-plated brass contacts provide low resistance and reliable conductivity suitable for currents up to 3.5 amperes and voltages up to 150 volts. These spring loaded contacts accommodate mechanical vibrations and ensure consistent connectivity and electrical performance, making the product highly durable and dependable in demanding industrial applications.

With an operating temperature range from -55 degrees Celsius to 125 degrees Celsius, this connector is appropriate for a wide variety of environments, from laboratory equipment to manufacturing automation systems. The shrouded design enhances mating reliability by preventing improper connections and protecting contacts from damage.

This Preci-Dip connector complies with UL 94V-0 flammability standards and originates from Switzerland, demonstrating high-quality manufacturing standards. It is especially suitable for electronic component interconnection in industrial, instrumentation, and electronic assembly sectors.

Straight through hole mounting for PCB connectivity. 6 gold-plated spring loaded brass contacts for durable electrical connection. Fibreglass reinforced polyethylene terephthalate housing for mechanical robustness. Shrouded to ensure protection and correct mating.

3.5 A current rating and 150 V voltage capability. Wide operating temperature range from -55°C to 125°C. Male contact gender suitable for corresponding female connectors.

This connector is part of EnvMart’s extensive range of industrial-grade PCB Connectors. Customers can select reliable and high-performance components for demanding electronics and power applications with confidence.
