Hirose DF3 Series Straight Through Hole PCB Header, 12 Contacts, 2 mm Pitch, 1 Row, Shrouded DF3A-12P-2DSA

Free Delivery in India | Lowest Global Shipping Charges

Hirose DF3 Series Straight Through Hole PCB Header, 12 Contacts, 2 mm Pitch, 1 Row, Shrouded DF3A-12P-2DSA

Name: Hirose DF3 Series Straight Through Hole PCB Header, 12 Contacts, 2 mm Pitch, 1 Row, Shrouded DF3A-12P-2DSA
Brand: Hirose
SKU: 214842



Category PCB Connectors Brand Hirose Condition New

Specifications

Country of Origin	Japan
Voltage	250V
Brand	Hirose
Orientation	Straight
Current	3A
Model	DF3A-12P-2DSA
Mount Type	Through Hole
Housing Material	Polyamide
Contact Material	Copper Alloy
Series	DF3
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-30°C
Number of Rows	1
Pitch	2mm
Contact Plating	Tin
Number of Contacts	12
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board

Key Features

Rated for a maximum current of 3 amperes.
Constructed with polyamide housing material for durability.
Termination is solder type with copper alloy contacts plated in tin.
Designed for board-to-board and wire-to-board connector systems.
Through-hole mount type ensures secure PCB attachment.
Operating temperature range from -30°C to 85°C suitable for various environments.
Male contact gender with a 0.8 mm board through-hole diameter.
Shrouded to protect contacts and improve connection reliability.

Product Description

Hirose DF3A-12P-2DSA is a high-quality PCB header from the DF3 series featuring a straight through hole design, 12 contacts arranged in a single row with a 2 mm pitch, and a shrouded housing for added protection. It is optimized for board-to-board and wire-to-board connections, providing reliable electrical performance in various electronic applications.

The connector employs a polyamide housing material which offers mechanical strength and temperature resistance in a range from -30°C to 85°C, making it suitable for industrial and electronic manufacturing use cases. Its copper alloy contacts plated with tin ensure stable conduction and solder termination allows for secure PCB mounting via through holes with a diameter of 0.8 mm.

Rated for currents up to 3 amperes and voltage up to 250 volts, this male contact type header supports demanding circuit board interconnects. The shrouded design not only guards the contacts but also enhances handling and protection during assembly.

Manufactured in Japan, the DF3A-12P-2DSA header meets rigorous quality standards and is widely used in electronics manufacturing, industrial control systems, telecommunications equipment, and other commercial electronics requiring durable and reliable connectors.

Rated current of 3 amperes for moderate power applications. Polyamide housing material for robustness and thermal endurance. 2 mm pitch and 12 contacts optimize board space and signal density. Straight orientation for direct board insertion compatibility.

Through-hole mount type enhancing mechanical stability. Solder termination for strong electrical and mechanical joint. Operating temperature range of -30°C to 85°C for varied environments. Voltage rating of 250 volts to support many electronic circuit standards.

Shrouded connector design for contact safety and handling. Made in Japan ensuring manufacturing quality and compliance. Explore more Hirose connectors and PCB header solutions in EnvMart's Electronics & Electricals category for reliable industrial and commercial applications.
