Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 12 Contacts, 2.54 mm Pitch, 1 Row 811-S1-012-10-014101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 12 Contacts, 2.54 mm Pitch, 1 Row 811-S1-012-10-014101

Name: Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 12 Contacts, 2.54 mm Pitch, 1 Row 811-S1-012-10-014101
Brand: Preci-Dip
SKU: 215247
Price: 14.94 USD
Availability: InStock



Category PCB Connectors Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	3.5A
Model	811-S1-012-10-014101
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Series	811
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	12
Contact Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

Features a 2.54 mm pitch and single row configuration.
Constructed with brass contacts plated with gold for low resistance and durability.
Housing made of fibreglass reinforced polyethylene terephthalate ensures mechanical strength.
Designed for through-hole mounting with shrouded orientation.
Operates reliably between temperatures of -55°C to 125°C.
Supports a current rating of 3.5 A and voltage up to 150 V.
The spring-loaded contact design ensures stable, low resistance connections even under vibration.
Compact plastic body height of 4 mm with plunger stroke length of 1.4 mm.

Product Description

Preci-Dip 811-S1-012-10-014101 Spring Loaded Connector is engineered for precision PCB connections with 12 gold-plated brass contacts arranged in a single row at a 2.54 mm pitch. This shrouded connector is designed for through-hole mounting and features a robust fibreglass reinforced polyethylene terephthalate housing that offers excellent mechanical stability.

The spring-loaded contacts ensure low, stable electrical resistance, providing reliable multipoint electrical connections even in applications with mechanical vibration or movement. The connector has an operating temperature range from -55°C to 125°C, a current rating of 3.5 A, and a voltage rating of 150 V, making it suitable for demanding industrial and electronic applications.

The compact design with a 4 mm plastic body height and a 1.4 mm plunger stroke length facilitates space-saving PCB assembly. It is an excellent choice for industrial, laboratory instrumentation, manufacturing, automation, and power connector needs.

Features a 2.54 mm pitch and single row configuration. Constructed with high-quality brass contacts and gold plating for corrosion resistance. Fibreglass reinforced housing provides strength and durability. Ensures consistent electrical contact with spring-loaded technology.

Rated for 3.5 A current and 150 V voltage. Operates across a wide temperature range (-55°C to 125°C). Shrouded design enhances connector protection and polarization. Allows through-hole mounting for secure PCB integration.

Compact size and plunger stroke suitable for precise connections.

This Preci-Dip connector delivers performance for electronics in various sectors including industrial controls, automation equipment, test instrumentation, and manufacturing systems.
