Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector 5 Contacts 2.54 mm Pitch 1 Row 811-S1-005-10-014101

Preci-Dip 811-S1-005-10-014101 is a high-quality spring loaded connector designed for through hole PCB mounting applications. Featuring 5 male contacts arranged in a single row with a 2.54 mm pitch, this connector ensures secure and reliable electrical connections in demanding environments.

The spring loaded contacts utilize a multipoint electrical connection system between the mobile piston and the clip, guaranteeing low and stable electrical resistance values without micro-discontinuities even during mechanical vibrations or piston movements. This design is critical for industrial, telecommunications, and electronic manufacturing applications where consistent signal integrity is essential.

The connector's housing made from fibreglass reinforced polyethylene terephthalate offers robustness while maintaining electrical insulation standards. Brass contacts plated with gold provide excellent conductivity and corrosion resistance, ensuring long service life.

Designed for operation across a wide temperature range from -55°C to 125°C, this connector supports a maximum current of 3.5 A and voltage of 150 V. Its shrouded form factor adds an extra layer of protection for both the contacts and the mating connector.

The product is manufactured in Switzerland under stringent quality controls and complies with UL 94V-0 insulation standards. The plunger stroke length of 1.4 mm and plastic body height of 4 mm offer precise mechanical engagement and durability.

Spring loaded contacts ensure reliable low-resistance connections during vibration. Shrouded, through hole design protects contacts and supports PCB mounting. Gold plated brass contacts for durability and corrosion resistance.

Fibreglass reinforced housing for electrical insulation and mechanical strength. Wide operating temperature range from -55°C to 125°C. Supports up to 3.5 A current and 150 V voltage rating. Single row, 5 contact configuration with 2.54 mm pitch.

Manufactured in Switzerland for high-quality standards.

This spring loaded connector is ideal for electronic component assembly, power and signal connections in industrial automation, telecommunications, and instrumentation fields. It ensures secure and maintenance-free operation in demanding environments.
