Preci-Dip 110 2.54 mm Pitch Vertical 42 Way Through Hole Turned Pin Open Frame DIL Socket 1A 110-87-642-41-001101

Preci-Dip 110-87-642-41-001101 is a precision-manufactured vertical 42 way Dual-In-Line (DIL) open frame socket designed for electronic components requiring 2.54 mm pitch spacing. This through hole mounted socket facilitates robust PCB integration with durable turned pins that support 1A current.

The open frame construction enhances ease of inspection during assembly and supports reflow soldering techniques, including vapor phase soldering with gull wing terminations. Its housing is fabricated from fibreglass reinforced polyethylene terephthalate, providing excellent mechanical stability and resistance to environmental stress.

Contacts are crafted from brass combined with a beryllium copper alloy that assures high electrical conductivity and mechanical strength. The contact surfaces are plated with tin and gold flash, delivering reliable corrosion resistance and signal integrity.

Its vertical orientation and solder termination type simplify mounting onto standard PCBs, suitable for a variety of industrial electronics applications. The socket is rated for operation within a temperature range from -55°C up to 125°C, ensuring dependable performance under demanding environmental conditions.

Standard electrical ratings include voltage tolerance up to 150V AC and current capacity of 1A, making it suitable for low power circuit applications in control systems, industrial equipment, and electronic testing devices.

The compact form factor with dimensions approximately 53.3 mm in length, 17.7 mm width, and 2.8 mm depth supports space efficient PCB layouts in laboratory, manufacturing, and industrial instrumentation sectors.

42 contact pins with 2.54 mm pitch for precise IC socket connections. Through hole mount type ensures secure PCB attachment. Open frame design supports easy inspection and reflow soldering. Operates within temperature range -55°C to 125°C ensuring reliability.

Housing made of fibreglass reinforced polyethylene terephthalate for durability. Contact material brass with beryllium copper alloy provides excellent conductivity. Contact plating features tin and gold for reliable electrical performance.

Vertical orientation with solder termination type suitable for assembly processes. Dimensions approximately 53.3 mm length, 17.7 mm width, and 2.8 mm depth. Voltage rating up to 150 V AC ensuring compatibility with diverse circuits.

This Preci-Dip 110 series DIL socket model enables effective electronic component interfacing in industrial, laboratory, and prototype PCB applications. It ensures high reliability and ease of maintenance in various environments requiring secure electrical connections and modular component placement.
