RS PRO 2.54 mm Pitch Vertical 20 Way Through Hole Turned Pin Closed Frame DIL Socket 3A 183-1566
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 60, 60V ac |
| Brand | RS PRO |
| Orientation | Vertical |
| Current | 3A |
| Frame Type | Closed Frame |
| Length | 25.4mm |
| Model | 183-1566 |
| Depth | 3mm |
| Width | 10.16mm |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Beryllium Copper Alloy, Brass |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Pitch | 2.54mm |
| Contact Plating | Gold, Tin |
| Number of Contacts | 20 |
| Pin Type | Turned |
| Row Width | 7.62mm |
Key Features
- Features a closed frame design to prevent flux intrusion during soldering.
- Gold and tin contact plating ensures reliable electrical connections.
- Constructed with beryllium copper alloy and brass contacts for durability.
- Thermoplastic housing supports high-temperature operation up to 105°C.
- Suitable for vertical mounting with a 7.62 mm row width and 10.16 mm socket width.
- Operates reliably within -40°C to 105°C temperature range.
- Designed for solder termination in through hole mounting applications.
- Provides excellent repeat insertion performance with stamped spring copper contacts.
Product Description
RS PRO 183-1566 is a precision engineered 2.54 mm pitch vertical 20-way through hole DIL socket featuring turned pins. It supports a maximum current rating of 3A and a voltage rating of 60 V AC, making it suitable for diverse electronic circuit applications. This socket has a closed frame design that effectively prevents flux intrusion and solder wicking during manufacturing, enhancing long-term reliability.
Its contacts are made from beryllium copper alloy and brass, providing excellent conductivity and mechanical strength. The contact plating options of gold and tin deliver reliable electrical contact and corrosion resistance. The housing is molded from a high temperature thermoplastic capable of enduring operating temperatures from -40°C to 105°C.
The vertical orientation and standard 7.62 mm row width make it compatible with common PCB layouts. Termination is via soldering to through hole mounts, supported by solid, precision turned sleeves and stamped spring copper insert contacts offering excellent insertion and withdrawal durability for repeated use in industrial, laboratory, and manufacturing environments.
Features a closed frame design to prevent flux intrusion during soldering. Gold and tin contact plating for enhanced electrical reliability. Beryllium copper alloy and brass materials ensure durability. Thermoplastic housing withstands high temperature operations.
Vertical orientation with 7.62 mm row width and 10.16 mm width. Rated for 3A current and 60 V AC voltage. Suitable for through hole solder termination. Reliable contact insertion and withdrawal performance. Operating temperature range between -40°C and 105°C.
Manufactured in China.
This DIL Socket is an ideal choice for electronic assemblies requiring reliable connections and ease of repeated insertion/removal. Its robust design supports industrial, electronic manufacturing, and laboratory equipment applications. Browse more quality RS PRO components on EnvMart for your electronic needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this DIL socket is 3A.
This model has a voltage rating of 60V AC.
The contacts are made from beryllium copper alloy and brass, ensuring reliable electrical connections.
It operates reliably within a temperature range of -40°C to 105°C.
This socket uses solder termination for through hole mounting applications.
The pitch size of this DIL socket is 2.54 mm.
This DIL socket features 20 contacts.
It has a closed frame design that helps prevent flux intrusion during soldering.
The dimensions are 25.4 mm in length, 10.16 mm in width, and 3 mm in depth.
This model is designed for vertical orientation.
The housing is made from thermoplastic, supporting high-temperature operation.
This product is manufactured in China.
