Preci-Dip 110 Series 2.54 mm Pitch Vertical 50 Way Through Hole Turned Pin Open Frame DIL Socket 1A 110-87-650-41-001101

Preci-Dip 110-87-650-41-001101 is a high-quality 50 way Dual-In-Line (DIL) socket with a 2.54 mm pitch, designed for vertical through-hole mounting applications. This open frame DIL socket supports a current rating of 1 ampere and features turned pin contacts plated with gold and tin for reliable electrical connections. Its sturdy fibreglass reinforced polyethylene terephthalate housing offers durability and long service life, suitable for industrial and manufacturing use cases.

The socket accommodates standard DIP integrated circuits with precise spacing and robust mechanical retention, measuring 63.5 mm in length, 17.7 mm in width, and 2.8 mm in depth. It operates effectively across a wide temperature range from -55°C to 125°C, making it ideal for demanding environments including electronic assembly, lab instrumentation, and industrial control systems.

The contact pins are composed of brass and beryllium copper alloy, combining excellent conductivity with mechanical strength. The open frame design facilitates easy inspection and testing of mounted components. Manufactured to Swiss quality standards, this socket ensures consistent performance and reliability.

Offers 50 contacts with 2.54 mm pitch spacing for DIP components. Through hole mounting with vertical orientation for PCB integration. Durable fibreglass reinforced PET housing designed for industrial applications. Gold and tin contact plating enhances conductivity and corrosion resistance.

Operates from -55°C to 125°C, suitable for a wide range of environmental conditions. Compact dimensions of 63.5 x 17.7 x 2.8 mm enable space-efficient PCB design. Contact pins comprise brass and beryllium copper alloy for reliable connections.

Open frame design allows easy visual inspection and testing of socketed components. Manufactured in Switzerland to exacting quality standards for dependable use.

This DIL Socket serves a broad spectrum of industrial sectors including electronics manufacturing, laboratory instrumentation, power and control equipment assembly, and various commercial electronic applications. It is compatible with standard 50-pin DIP integrated circuits, offering a reliable and maintainable solution for PCB mounting challenges.
