E-TEC 2.54 mm Pitch Vertical 22 Way Through Hole Turned Pin Open Frame DIL Socket 3A POS-422-S001-95 X30
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V |
| Brand | E-TEC |
| Orientation | Vertical |
| Current | 3A |
| Temperature range | -65°C to +125°C |
| Frame Type | Open Frame |
| Model | POS-422-S001-95 X30 |
| Depth | 2.8mm |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Beryllium Copper Alloy |
| Series | POS/POO/PCL |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Pitch | 2.54mm |
| Contacts | Beryllium copper |
| Contact Plating | Gold, Tin |
| Number of Contacts | 22 |
| Pin Type | Turned |
| Pins | Brass |
| Row Width | 10.16mm |
| 22 way precision DIP socket,0.4in pitchBrand | E-TEC |
Key Features
- The socket features precision gold plated tulip grip contacts for high conductivity.
- Open frame construction ensures effective heat dissipation during operation.
- Constructed with beryllium copper alloy contacts and polybutylene terephthalate housing for durability.
- Vertical orientation and solder termination type enables secure PCB mounting.
- Designed for operating temperatures up to 125°C and a voltage rating of 500V.
- Offers excellent insulation resistance, exceeding 5 x 10⁹ Ω at 500Vdc on standard materials.
- Contact pins are brass with tin plating to prevent capillary action during soldering.
- Suitable for industrial and electronic equipment PCB assemblies requiring precise and durable connections.
Product Description
E-TEC POS-422-S001-95 X30 is a 22 way vertical DIL Socket designed for through-hole mounting on printed circuit boards. It features a 2.54 mm pitch and turned pins that provide a reliable mechanical and electrical connection.
The open frame design optimizes heat dissipation to enhance operational stability, making it suitable for demanding industrial applications. Contacts use precision gold plating with tulip grip construction to ensure low resistance and robust signal integrity.
The housing material is polybutylene terephthalate which offers excellent mechanical strength and thermal stability within the range of -65°C to +125°C. The contact material is beryllium copper alloy, chosen for its superior conductivity and resilience, while pins are brass with tin plating to resist solder capillary effects.
This socket supports a current rating of 3A and voltage rating of 500V, designed to meet the needs of power and signal connector applications in electronics manufacturing, automotive electronics, and control systems.
Key performance features include high insulation resistance of 5 x 10⁹ Ω at 500Vdc and a contact life exceeding 100 cycles, ensuring durability and reliability in repetitive connect-disconnect scenarios.
Precision gold plated 'tulip' grip contacts enhance conductivity and longevity. Open frame construction maximizes heat dissipation and operational safety. Robust construction using beryllium copper alloy contacts and PBT housing.
Rated for 3A current and 500V voltage for demanding electronic applications. Vertical through-hole solder termination supports secure PCB integration. Operating temperature range from -65°C to +125°C suits harsh environments.
High insulation resistance guarantees effective electrical isolation. Suitable for industrial, electronic assembly, and manufacturing use.
Set within the POS/POO/PCL series, this 22 way DIP socket offers a row width of 10.16 mm with a compact 2.8 mm depth, ensuring component density without compromising ease of assembly.
Explore a broad selection of electronic components and connectors within EnvMart’s extensive catalogue for your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3A, making it suitable for various electronic applications.
The voltage rating for this socket is 500V, allowing it to handle high voltage applications effectively.
The contacts in this socket have a pitch size of 2.54 mm, which is standard for many electronic components.
The housing is made from polybutylene terephthalate, while the contacts are constructed from beryllium copper alloy, providing good conductivity and durability.
It operates within a temperature range of -65°C to +125°C, suitable for harsh environmental conditions.
This socket uses a solder termination type, which ensures secure mounting on printed circuit boards.
This model features 22 contacts, allowing for multiple connections in a compact design.
The socket has an open frame design, which helps optimize heat dissipation during operation.
The depth of this socket is 2.8 mm, contributing to its compact form factor.
It offers an insulation resistance exceeding 5 x 10⁹ Ω at 500Vdc, ensuring effective electrical isolation.
This socket is designed for use in industrial and electronic equipment PCB assemblies that require precise and durable connections.
The socket uses turned pins, which provide a reliable mechanical and electrical connection.
