Preci-Dip 2.54 mm Pitch Vertical 18 Way Surface Mounted Turned Pin Open Frame DIL Socket 110-87-318-41-105101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V dc |
| Brand | Preci-Dip |
| Orientation | Vertical |
| Current | 1A |
| Frame Type | Open Frame |
| Length | 22.8mm |
| Depth | 2.8mm |
| Width | 10.1mm |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass, Beryllium Copper Alloy |
| Series | 110 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.54mm |
| Contact Plating | Gold, Tin |
| Number of Contacts | 18 |
| Pin Type | Turned |
| Row Width | 7.62mm |
| Stock numbers | 702-0691 , 702-2704 , 702-2701 , 702-2713 , 702-2767, 702-2779 , 702-2773 , 702-2798 and 702-2808 are without a centre bar |
Key Features
- Provides a current rating of 1A at 150V DC for reliable operation.
- Features an open frame design with brass and beryllium copper alloy contacts.
- Gold and tin plated contacts ensure excellent conductivity and corrosion resistance.
- Made of fibreglass reinforced polyethylene terephthalate housing for durability.
- Operates at temperatures ranging from -55°C to a maximum of 125°C.
- Designed for surface mounting using solder termination with vertical orientation.
- Swiss origin product ensuring high-quality manufacturing standards.
- Suitable for industrial electrical and electronic applications requiring DIP sockets.
Product Description
Preci-Dip 110-87-318-41-105101 is a high-quality vertical 18 way Dual-In-Line (DIL) socket featuring a 2.54 mm pitch and surface mount design. This open frame socket incorporates turned pin contacts with gold and tin plating for optimum electrical connectivity and durability. The contact material consists of brass and beryllium copper alloy, ensuring excellent mechanical strength and conductivity.
The housing is constructed from fibreglass reinforced polyethylene terephthalate, providing mechanical robustness and thermal stability. Designed to operate reliably within a temperature range of -55°C to 125°C, this socket is ideal for demanding industrial and commercial electronics environments.
Its compact dimensions (22.8 mm length, 10.1 mm width, 2.8 mm depth, and a row width of 7.62 mm) make it well-suited for integration on printed circuit boards (PCB) with surface mount solder termination and vertical orientation for convenient installation and testing.
This Swiss-manufactured DIL Socket serves applications in industrial electronics, control systems, measurement instruments, and other electronic assembly lines requiring precise and secure IC socketing solutions. Use of this product enhances repairability and reduces assembly time in manufacturing processes.
Current rating of 1A at 150V DC for safe operation. Surface mount design supports robust reflow soldering techniques. Open frame construction for easy inspection and testing of inserted ICs. High-quality gold flash contact clips maintain signal integrity.
Reliable contact retention with four-finger clips. Ideal for laboratory, manufacturing, and repair environments in electronics.
Preci-Dip sockets are trusted components in electronics manufacturing, enabling easy and reliable IC insertion/removal. This 110 Series product ensures superior electrical performance and mechanical stability.
Explore our extensive electronics components catalog for compatible sockets, connectors, and adapters to complete your electronic design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a current rating of 1A at 150V DC for reliable operation.
The maximum operating temperature is 125°C, while the minimum is -55°C.
The contacts are made of brass and beryllium copper alloy, with gold and tin plating for excellent conductivity and corrosion resistance.
The pitch size is 2.54 mm, making it suitable for standard applications requiring this spacing.
It measures 22.8 mm in length, 10.1 mm in width, and 2.8 mm in depth, with a row width of 7.62 mm.
This model supports surface mounting using solder termination with vertical orientation.
The housing is made from fibreglass reinforced polyethylene terephthalate, providing mechanical robustness and thermal stability.
It features 18 contacts, designed for secure IC socketing solutions.
The socket has an open frame design, which allows for easy inspection and testing of inserted ICs.
It is suitable for industrial electronics, control systems, measurement instruments, and other electronic assembly lines.
This model uses turned pin contacts, which enhance the reliability of electrical connections.
This product is manufactured in Switzerland, ensuring high-quality manufacturing standards.
