HARWIN D2 7.62 mm Pitch Vertical 14 Way Through Hole Standard Pin Open Frame DIL Socket D2814-42

HARWIN D2814-42 is a high-quality 14 way DIL (Dual In-Line) socket featuring a 7.62 mm pitch and vertical orientation. This open frame socket is designed for through hole mounting on printed circuit boards, facilitating stable electrical connections for standard pins carrying currents up to 1 ampere.

Constructed with beryllium copper alloy contacts plated with tin over nickel and gold, the socket ensures excellent conductivity and corrosion resistance. Its robust plastic housing offers mechanical stability while integrating seamlessly into electronic assemblies.

The socket supports operating temperatures ranging from -55°C to 125°C, making it resilient for industrial, laboratory, and commercial electronics applications that demand reliability across environmental extremes.

Key mechanical dimensions include a length of 17.7 mm, width of 10.02 mm, and a depth of 2.8 mm, allowing compact and precise placement on PCB assemblies. The 0.3 inch (7.62 mm) pitch and row width help accommodate 0.40 - 0.56 mm diameter mating pins with ease, improving design flexibility.

This DIL socket is rated for AC voltages between 100 V and 150 V, making it suitable for low power signal interfaces. The solder termination type enables robust solder joints during PCB assembly processes.

As a product made in Switzerland, this HARWIN D2 series socket complies with high manufacturing standards and is ideal for electronics engineers, technicians, and researchers in industrial manufacturing, automation, and test equipment.

This socket features an open frame design suitable for various electronics applications. It supports a 7.62 mm pitch with a row width of 7.62 mm for precise component alignment. The contacts are made of beryllium copper alloy with tin over nickel and gold plating for reliable conductivity.

It is designed for vertical orientation and has a mounting type of through hole with solder termination. Operating temperature ranges from -55°C to 125°C, ensuring durability in harsh conditions. The socket dimensions are 17.7 mm length, 10.02 mm width, and 2.8 mm depth for compact PCB integration.

Suitable for mating pins with diameters between 0.40 and 0.56 mm, ensuring compatibility. The voltage rating is 100 to 150 V AC with a contact current of 1A, suitable for low power circuits. This product is made in Switzerland and offers high quality for industrial and laboratory electronic projects.
