Smartscan 24V DC Safety Relay with 2 Safety Contacts and 1 Auxiliary Contact 011-149

Smartscan 011-149 is a 24V DC safety relay featuring 2 safety contacts and 1 auxiliary contact designed for use in industrial automation and safety control systems. This relay provides reliable operation and a smart, affordable solution for machine safety applications.

The product includes LED status indicators which offer immediate visual feedback on power, input, and external device monitoring (EDM) status, facilitating quick safety assessments. Both automatic and manual reset options are provided, enabling greater control flexibility depending on the installation and operational requirements.

Designed for DIN Rail mounting, the relay’s dimensions are 70mm width, 60mm height, and 90mm length, allowing integration into compact control panels. Its fail-safe contacts are rated for 250V AC at 4 amperes, suitable for a variety of safety switching applications.

Compliance with EN ISO 13849 (Category 3) and IEC 61496-1 Type 2 standards ensures high safety performance and reliability. The relay also includes an external device monitor to detect faults such as welded contacts, enhancing operational safety.

A third mute input channel is incorporated, providing a guard override function, particularly useful in automated packaging industries to temporarily bypass light curtains while still ensuring personnel safety.

The device is rated with an IP40 ingress protection class, making it suitable for indoor industrial environments. Its operating temperature range is from 0°C to 50°C, supporting dependable performance in typical factory conditions.

The Smartscan 011-149 safety relay is manufactured in the United Kingdom, and conforms to RoHS directives. It carries important certifications from SAFENET under the Machinery Directive, ensuring regulatory compliance and safety assurance.

Equipped with LED status indicators for quick visual safety checks. Includes automatic and manual reset functions for operational flexibility. DIN Rail mountable enclosure measuring 70mm width for compact installation. Safety outputs rated at 250V AC, 4A with fail-safe changeover contacts.

Conforms to safety standards EN ISO 13849 and IEC 61496-1 Type 2. Operational temperature range from 0°C to 50°C ensuring reliable performance. Features external device monitoring to detect relay faults such as welded contacts.

Provides a third mute input channel to enable guard override in automated packaging processes. IP40 rated housing for adequate protection in industrial environments. Country of origin is United Kingdom. Explore more products in the Safety Relay category available at EnvMart for enhanced industrial safety and automation solutions.
