Preci-Dip 110 Series 2.54 mm Pitch Vertical 24 Way Through Hole Turned Pin Open Frame DIL Socket 110-87-424-41-001101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 110 Series 2.54 mm Pitch Vertical 24 Way Through Hole Turned Pin Open Frame DIL Socket 110-87-424-41-001101

Name: Preci-Dip 110 Series 2.54 mm Pitch Vertical 24 Way Through Hole Turned Pin Open Frame DIL Socket 110-87-424-41-001101
Brand: Preci-Dip
SKU: 215429
Price: 2.6 USD
Availability: InStock



Category DIL Socket Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	100, 150V ac
Brand	Preci-Dip
Orientation	Vertical
Current	1A
Frame Type	Open Frame
Length	30.4mm
Depth	2.8mm
Width	12.6mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass, Beryllium Copper Alloy
Series	110
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Tin, Gold
Number of Contacts	24
Pin Type	Turned
Row Width	10.16mm
Stock numbers	702-0691 , 702-2704 , 702-2701 , 702-2713 , 702-2767, 702-2779 , 702-2773 , 702-2798 and 702-2808 are without a centre bar

Key Features

This socket features a 2.54 mm pitch with 24 vertical contact points.
Constructed with a brass and beryllium copper alloy contact material for reliability.
Featuring an open frame made from fibreglass reinforced polyethylene terephthalate.
Supports currents up to 1 ampere and voltages of 100 to 150 volts AC.
Solder termination type suitable for through hole mounting on PCBs.
Operating temperature ranges from -55°C to 125°C, suited for industrial environments.
The pin type is turned, with contact plating of tin and gold flash for enhanced conductivity.
Manufactured in Switzerland ensuring high-quality standards.

Product Description

Preci-Dip 110-87-424-41-001101 is a 2.54 mm pitch vertical 24 way through hole turned pin open frame DIL socket designed for secure and reliable connections in electronic assemblies. Constructed with high-quality materials including brass and beryllium copper alloy contacts, it ensures excellent electrical performance and durability.

The housing is made from fibreglass reinforced polyethylene terephthalate, providing mechanical strength and stability. This open frame socket supports operating temperatures from -55°C to 125°C, making it suitable for industrial, laboratory, manufacturing, and commercial electronic applications.

It supports a current rating of 1A and can handle voltages up to 150V AC, suitable for various low-power electronic circuits. The contact plating consists of tin with a gold flash, enhancing conductivity and resistance to corrosion.

The socket is designed for through hole mounting with solder terminations, ensuring strong and reliable attachment to printed circuit boards. Its vertical orientation and 24 contacts spaced at the standard 2.54 mm pitch make it compatible with many integrated circuit designs, facilitating easy insertion and removal.

Dimensions are precise with a length of 30.4 mm, width of 12.6 mm, depth of 2.8 mm, and row width of 10.16 mm, fitting common electronic assembly footprints. This DIL socket offers a robust construction with brass and beryllium copper alloy contacts.

It features tin and gold contact plating for optimal electrical performance. Operating temperature range of -55°C to 125°C suits demanding environments. The open frame design allows easy inspection and maintenance. Suitable for through hole PCB mounting with vertical orientation.

Reliable for industrial electronics, manufacturing, and laboratory use. Manufactured in Switzerland ensuring strict quality controls.

This product is ideal for engineers and technicians seeking a durable and reliable DIL Socket for electronic component mounting and testing. Browse further in Electronics Components for additional socket options suitable for your projects.
