Preci-Dip 32 Way 2.54 mm Pitch Vertical Through Hole Turned Pin Open Frame DIL Socket 1A 110-87-432-41-001101

Preci-Dip 110-87-432-41-001101 is a 32 way Dual-In-Line (DIL) socket featuring a 2.54 mm pitch and vertical orientation, designed for through-hole mounting applications. This open frame DIL socket employs turned pins that facilitate excellent solder connections, making it ideal for industrial electronics manufacturing, testing, and maintenance.

The socket utilizes high-quality beryllium copper alloy and brass for contacts, combined with a robust fibreglass reinforced polyethylene terephthalate housing to withstand mechanical stress and temperature ranges from -55°C to 125°C. The contact pins are plated with tin and enhanced with a gold flash to prevent corrosion and ensure high conductivity. Operating voltage is rated at 100V and 150V AC with a current capacity of 1A, suitable for various electronic circuits.

The socket’s design incorporates a 10.16 mm row width and compact dimensions (length 40.6 mm, width 12.6 mm, depth 2.8 mm), conserving PCB space while maintaining reliability. The solder termination type ensures a dependable attachment to circuit boards, supporting industrial and laboratory applications such as PCB testing, prototyping, and production line assembly.

This series is part of the Preci-Dip 110 lineup, well-regarded for precision and durability. The product is manufactured in Switzerland, meeting quality standards for electronics components.

Features 32 contacts with a 2.54 mm pitch for precise component alignment. Constructed with beryllium copper alloy and brass contact material for durability. Open frame design with turned pin type ensures efficient soldering and connection.

Contact plating uses tin with a gold flash for corrosion resistance and conductivity. Operates under voltage ratings of 100 and 150V AC with a current rating of 1A. Supports operating temperatures from -55°C to 125°C for diverse environmental conditions.

Housing made from fiberglass reinforced polyethylene terephthalate for mechanical stability. Vertical orientation and a row width of 10.16 mm optimize PCB space utilization. Termination type is solder for secure mechanical and electrical fixation.

Compact dimensions: length 40.6 mm, width 12.6 mm, and depth 2.8 mm for optimized PCB footprint.

This Preci-Dip DIL socket is widely used in electronic manufacturing, testing environments, and PCB assembly lines in industrial, laboratory, and commercial electronics sectors. For more options in DIL Sockets and related PCBs components, explore EnvMart’s comprehensive catalog.
