Preci-Dip 800 Series Straight Surface Pin Header 2 Contact 2.54 mm Pitch 1 Row Unshrouded 800-80-002-30-480101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 800 Series Straight Surface Pin Header 2 Contact 2.54 mm Pitch 1 Row Unshrouded 800-80-002-30-480101

Name: Preci-Dip 800 Series Straight Surface Pin Header 2 Contact 2.54 mm Pitch 1 Row Unshrouded 800-80-002-30-480101
Brand: Preci-Dip
SKU: 215222
Price: 0.48 USD
Availability: InStock



Category PCB Headers Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	3A
Mount Type	Surface
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Series	800
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	2
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded

Key Features

The header has 1 row and is unshrouded for easy access.
Contacts are made of brass with tin plating enhancing conductivity and corrosion resistance.
Housing is made of fibreglass reinforced polyethylene terephthalate ensuring durability.
Suitable for surface mount with a straight orientation for space-efficient PCB design.
Operates safely within -55°C to 125°C temperature range.
Rated for 3A current and supports up to 150V voltage.
The solder termination type provides robust mechanical and electrical connection.
Manufactured in Switzerland ensuring high quality standards.

Product Description

Preci-Dip 800-80-002-30-480101 800 Series Straight Surface Pin Header is a high-quality PCB connector designed for industrial and electronic applications requiring reliable interconnections. This header features 2 brass contacts plated with tin for optimum electrical performance and corrosion protection.

The housing is constructed from fibreglass reinforced polyethylene terephthalate, providing enhanced durability and resistance to mechanical stress. The connector is built with a 2.54 mm pitch and a single row of contacts in a straight orientation, making it suitable for compact PCB layouts and high-density connections.

Its surface mount configuration and unshrouded design offer ease of soldering and maintenance without compromising electrical integrity. The connector tolerates operating temperatures from -55°C to 125°C, accommodating demanding environmental conditions.

Rated for a maximum current of 3A and a voltage of up to 150V, this pin header is ideal for use in various industrial, electronics manufacturing, and prototyping applications. Manufactured in Switzerland, it meets demanding quality and reliability standards.

The header has 1 row and is unshrouded for easy access. Contacts are made of brass with tin plating enhancing conductivity and corrosion resistance. Housing is made of fibreglass reinforced polyethylene terephthalate ensuring durability.

Suitable for surface mount with a straight orientation for space-efficient PCB design. Operates safely within -55°C to 125°C temperature range. Rated for 3A current and supports up to 150V voltage. The solder termination type provides robust mechanical and electrical connection.

Manufactured in Switzerland ensuring high quality standards.

This Preci-Dip PCB header is well suited for sophisticated electronics, power distribution boards, and industrial control systems, providing a dependable electrical connection that supports long-term operation.
