Nexperia 40 V 5 A Low Forward Voltage MEGA Schottky Barrier Rectifier Diode Surface Mount SOD-128 PMEG4050ETP,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 4mm |
| Model | PMEG4050ETP,115 |
| Width | 2.7mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-128 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 5A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 42mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 70A |
| Maximum Forward Voltage Vf | 490mV |
| Average forward current | IF(AV) ≤ 5 A |
| Reverse voltage | VR ≤ 40 V |
Key Features
- This diode features low forward voltage to improve efficiency in power applications.
- It is qualified to the automotive AEC-Q101 standard for high reliability.
- The device has a wide operating temperature range from -55°C to 175°C.
- Its planar MEGA technology ensures high power capability and stress protection.
- The compact 2-pin SOD-128 package saves PCB space in design layouts.
- Peak non-repetitive forward surge current capability is 70 A.
- Reverse leakage current is low at 42 mA max to minimize power loss.
- This diode is well suited for battery-powered and automotive electronics.
Product Description
Nexperia PMEG4050ETP,115 is a medium power low forward voltage Schottky barrier rectifier diode designed for surface mount applications in a small, flat SOD-128 plastic package.
With a maximum continuous forward current of 5 A and peak repetitive reverse voltage of 40 V, this diode supports efficient power rectification with minimal loss due to its low forward voltage drop of 490 mV.
The device incorporates planar MEGA technology with an integrated guard ring for stress protection, enabling high power capability and reliable operation under demanding conditions.
The diode is qualified to the automotive AEC-Q101 standard, ensuring suitability in automotive and industrial environments. Its wide operating temperature range from -55°C up to 175°C supports high temperature applications.
The compact 2-pin SOD-128 surface mount package optimizes board space, making it ideal for use in battery management, power supply circuits, and other power electronics requiring efficient rectification and low losses.
Low forward voltage improves energy efficiency in power conversion. Automotive-grade AEC-Q101 qualification certifies high reliability. Wide temperature capability supports harsh industrial environments. Compact SOD-128 package enables high-density PCB layouts.
High surge current tolerance for transient protection. Low reverse leakage current minimizes standby losses. Planar MEGA technology enhances durability and performance. Suitable for automotive, industrial, and battery-powered equipment.
This Schottky diode is typically used in power management modules, switching power supplies, automotive electronics, and other semiconductor circuit designs requiring efficient rectification with minimal voltage drop.
Explore more Nexperia power semiconductor devices and Schottky diode product lines on EnvMart to find tailored solutions for your industrial and automotive power electronics needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this diode is 5 A.
The peak reverse repetitive voltage rating is 40 V.
The maximum forward voltage drop is 490 mV.
The operating temperature range is from -55°C to 175°C.
The diode comes in a compact SOD-128 surface mount package.
This model has a 2-pin configuration.
It is qualified to the automotive AEC-Q101 standard for high reliability.
The maximum peak non-repetitive forward surge current is 70 A.
The maximum reverse leakage current is 42 mA.
This diode is a Schottky barrier rectifier.
It is typically used in power management modules, switching power supplies, and automotive electronics.
It incorporates planar MEGA technology, which enhances durability and performance.
