Nexperia Medium Power Schottky Diode 100 V 4.2 A Surface Mount SOD-128 PMEG10030ELPX
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 4mm |
| Model | PMEG10030ELPX |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | PMEG10030ELP |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-128 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 4.2A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1.5mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 70A |
| Maximum Forward Voltage Vf | 770mV |
| Peak Reverse Recovery Time trr | 8ns |
| Average forward current | IF(AV) ≤ 3 A |
| Reverse voltage | VR ≤ 100 V |
| onsemi 100 V 3 A Diode Schottky 2-Pin SOD-123 S310FABrand | onsemi |
Key Features
- This diode is designed to operate at a maximum temperature of 175°C.
- Its 2-pin single diode configuration supports efficient rectification.
- The device features a low forward voltage drop of 770 mV improving power efficiency.
- It supports a peak reverse voltage of 100 V and a peak forward surge current of 70 A.
- The diode is compliant with automotive standard AEC-Q101 ensuring reliability.
- Its compact dimensions of 4 mm length, 2.7 mm width, and 1.1 mm height enable space saving in circuits.
- The device provides fast switching with an 8 ns peak reverse recovery time.
- Leakage current is extremely low at 110 nA, enhancing performance in sensitive electronics.
Product Description
Nexperia PMEG10030ELPX is a medium power Schottky diode designed for efficient rectification and switching applications. It supports a maximum continuous forward current of 4.2 A and a peak reverse repetitive voltage of 100 V. This diode is housed in a compact SOD-128 surface mount package, making it suitable for modern electronics requiring small form factors.
The device features a low forward voltage of 770 mV, reducing power loss and improving energy efficiency in circuits. With a fast peak reverse recovery time of 8 ns and extremely low leakage current of 110 nA, it is optimized for high frequency operation and sensitive electronic applications. The diode can withstand a peak surge current of 70 A, enhancing robustness against transient events.
Designed to operate in a wide temperature range from -55°C to +175°C, this AEC-Q101 qualified component is ideal for automotive and industrial use cases where reliability is critical. Its integrated guard ring offers stress protection and extends component lifetime.
The diode's small size (4 mm length, 2.7 mm width, 1.1 mm height) allows space-saving PCB layouts in power supply circuits, battery management, and switching power systems across industrial, automotive, and consumer electronics sectors.
Medium power Schottky diode with low forward voltage for efficiency. Compact SOD-128 surface mount package for automated assembly. High surge current capability for enhanced durability. Wide operating temperature range -55°C to 175°C.
AEC-Q101 qualified for automotive grade reliability. Low leakage current ideal for sensitive electronic applications. Fast switching speed suitable for high frequency circuits. Integrated guard ring for stress protection.
Applications include industrial power supplies, battery chargers, automotive electronics, and consumer devices. Explore more Schottky diodes and related semiconductor components on EnvMart to find the right solution for your electronic circuit design needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 4.2 A.
This diode has a peak reverse repetitive voltage rating of 100 V.
The dimensions of the SOD-128 package are 4 mm in length, 2.7 mm in width, and 1.1 mm in height.
The forward voltage drop for this Schottky diode is 770 mV.
It can withstand a peak forward surge current of 70 A.
The operating temperature range for this diode is from -55°C to +175°C.
The peak reverse recovery time is 8 ns.
This model is compliant with the automotive standard AEC-Q101.
The leakage current is extremely low at 110 nA.
This diode features a single diode configuration.
It is suitable for applications including industrial power supplies, battery chargers, automotive electronics, and consumer devices.
This diode is housed in a SOD-128 surface mount package.
