TE Connectivity 1812 Shielded Wirewound Surface Mount Inductor with Ferrite Core 10μH ±10% 250mA 3613C100K

TE Connectivity 3613C100K is a shielded wirewound surface mount inductor designed for precision electronic applications requiring stable inductance and compact form factor. This inductor features a ferrite core and delivers an inductance value of 10μH with a tolerance of ±10%, suitable for circuits demanding consistent magnetic characteristics.

The device is packaged in an industry-standard 1812 surface mount case, measuring 4.5mm in length, 3.2mm in height and depth, making it ideal for automated SMT assembly on printed circuit boards. Its moulded construction and solder termination style enhance durability and ensure reliable mounting under varying operating conditions.

With a maximum DC current of 250mA and maximum DC resistance of 1.6Ω, this inductor balances electrical performance with thermal management efficiently. It operates reliably within the temperature range -30°C to 100°C, ensuring performance in both commercial and industrial environments. The shielding minimizes electromagnetic interference, improving circuit stability.

The inductor exhibits a high minimum quality factor of 50 and a maximum self-resonant frequency of 20MHz, attributes beneficial for high-frequency signal conditioning and filtering. Its RoHS compliance affirms adherence to environmental regulations.

Manufactured with ferrite core material and wirewound construction, the 3613C series inductors by TE Connectivity are engineered for a variety of applications including power supplies, automotive electronics, communication devices, and other precision electronic equipment. This product is made in Taiwan, Province Of China.

Inductance of 10 microhenrys with ±10% tolerance ensures precise performance. Maximum direct current rating of 250 milliamps suits medium current circuits. Compact 1812 package case dimension with 4.5mm length and 3.2mm height and depth.

Shielded construction with solder termination style for surface mounting reliability. Moulded wirewound inductor with ferrite core provides stability and durability. Operating temperature range from -30°C to 100°C allows use in varied environments.

Maximum DC resistance of 1.6 ohms limits power loss. High-quality factor of minimum 50 and self-resonant frequency up to 20 MHz for signal integrity. RoHS compliant ensuring environmental safety. Originated from Taiwan, Province Of China.

This TE Connectivity inductor is suitable for industrial, automotive, communication, and consumer electronics applications that require reliable inductance and EMI shielding. Browse more Surface Mount Inductors for precise magnetic components at EnvMart.
